Black Box LMC100A-SMLC-R2 Fast Ethernet Media Converter

The Black Box LMC100A-SMLC-R2 FlexPoint media converter provides reliable conversion between 10BASE-T/100BASE-TX copper Ethernet and 100BASE-FX single-mode fiber. Designed for flexible deployment, this standalone converter extends network connectivity up to 28 kilometers (17.3 miles) over fiber optic cable.

Key Features

• Converts 10/100 Mbps copper to 100 Mbps single-mode fiber with LC connector
• Extends distances up to 28 km (17.3 miles) over fiber
• Auto-sensing UTP port supports 10/100 Mbps speeds
• Full- and half-duplex operation on both UTP and fiber ports
• Manual override switch for precise control over port settings
• Built-in crossover switch for direct hub or switch connections
• IEEE 802.3 compliant (10BASE-T, 100BASE-TX, 100BASE-FX)
• Durable metal housing with ventilation

Applications

Ideal for extending LAN connectivity beyond copper distance limitations, connecting remote buildings, and integrating fiber backbone infrastructure with copper Ethernet networks. Can be deployed standalone, wall-mounted, DIN-rail mounted, or integrated into FlexPoint chassis systems for scalable network growth.
