Black Box FlexPoint 10/100 Media Converter

The Black Box LMC100A-SC-R3 FlexPoint media converter provides reliable copper-to-fiber connectivity for extending Fast Ethernet networks beyond traditional distance limitations. This standalone converter bridges 10BASE-T/100BASE-TX copper networks to 100BASE-FX fiber optic infrastructure, supporting transmission distances up to 2 kilometers over multimode fiber.

Key Features

• Converts between 10/100BASE-TX copper and 100BASE-FX multimode fiber (SC connector)
• Layer 2 switching capability with MAC address learning for up to 1024 addresses per port
• Auto-sensing 10/100 Mbps speed detection on copper port
• Full- and half-duplex operation on both UTP and fiber ports
• Manual override and crossover switches for flexible configuration
• IEEE 802.3 compliant for 10BASE-T, 100BASE-TX, and 100BASE-FX standards
• Transparent plug-and-play operation with no software required

Deployment Options

Install as a standalone unit with wall-mount hardware, integrate into the FlexPoint 5-Position Rackmount Kit, or deploy in the FlexPoint 14-Slot Power Chassis for centralized management. Ideal for industrial facilities, campus networks, and fiber backbone extensions requiring copper access points.
