Tripp Lite B064-016-01-IPG Cat5 KVM Switch Over IP 16-Port

Tripp Lite

Regular Price $3,611.20
Discount Price: $2,064.00
Product Overview:

Cat5 KVM Switch Over IP 16-Port w/Virtual Media 2 Users 1URM TAA - 16 Computer(s) - 1 Local User(s) - 1 Remote

Adding to cart… The item has been added


ripp Lite Cat5 KVM Switch Over IP 16-Port w/Virtual Media 2 Users 1URM TAA - 16 Computer(s) - 1 Local User(s) - 1 Remote User(s) - 19 x Network (RJ-45) - 2 x PS/2 Port - 6 x USB1 x VGA - Rack-mountable, Desktop - 1U - TAA Compliant WITH VIRTUAL MEDIA 2U 1U RM TAA

Cat5 KVM switch directly controls up to 16 computers and/or servers, including blade servers, at the same time.

Control As Many As 16 Computers or Servers from Anywhere in the World
This NetDirector® Cat5 KVM switch offers BIOS-level access to multiple computers and servers in a complex, demanding IT environment. The B064-016-01-IPG provides complete control of up to 16 computers and/or servers directly, including blade servers, from a single monitor, USB keyboard and USB mouse. Dual redundant power supplies confirm the unit will continue running in the event one power supply fails, ensuring 24/7 reliability. A Laptop USB Console (LUC) port allows direct connection of a laptop for easy console operation of the KVM switch.

All-in-One Network Management for Critical Systems
The B064-016-01-IPG offers a comprehensive, cost-effective network management solution that installs in 1U of space in an EIA-standard 19-inch rack using the included hardware. No server-resident software is required, so server performance and reliability are never compromised. Flash-upgradable firmware over an Ethernet network fine-tunes compatibility with emerging standards.

Supports All Major Operating Systems and Most Web Browsers
The B064-016-01-IPG supports all major server platforms and VT100-based serial devices. Because compatibility is based on common hardware standards, rather than system software dependencies, almost any platform can be accommodated. Supported web browsers for users who log in remotely include Internet Explorer, Firefox, Mozilla, Safari, Opera and Netscape Navigator.

Simple Network Control That Gives You More Flexibility
This Cat5 KVM switch is designed to ease multi-server management in data centers, server rooms and other high-density environments. Built-in IP capability allows up to two users-one local and one remote-to access the network independently and simultaneously. An optional dial-in connection (modem port) is provided to ensure access in situations when the KVM switch is not available over the primary network. You may also select a connected computer using on-console pushbuttons, GUI (graphical user interface), OSD (on-screen display) or keyboard hotkey commands. An LED per KVM port indicates when a computer is connected to the port, when it is powered on and when it is selected.

High-Resolution On-Screen Display Offers Multi-Language Support
The advanced OSD with high-resolution video up to 1920 x 1200 (at 60 Hz) with 24-bit color depth provides a GUI with management tools, including custom port labeling, auto-scanning and panel array mode. The OSD may be set to display in English, German, Russian, Japanese, traditional Chinese and simplified Chinese.

Allows Connection of Either PS/2 or USB Keyboard and Mouse
PS/2 and USB console ports are included. Only one keyboard/mouse combination may be connected at a time.

Supports Both IPv4 and IPv6 Addresses
The B064-016-01-IPG supports IPv4, Link Local IPv6 Address and IPv6 Stateless Autoconfiguration protocols. You may set the IP address manually or have it automatically assigned via DHCP server (the default method).


Power Description
Input Voltage Range 100 V AC - 240 V AC
Limited Warranty 3 Year
Technical Information
Maximum Operating Distance 164.04 ft
Number of Computers Supported 16
Number of Local Users Supported 1
Number of Remote Users Supported 1
Package Contents
  • B064-016-01-IPG 16-Port IP KVM Switch
  • 2 x C5 to NEMA 5-15P Detachable Power Cords
  • RJ45 to DB9 adapter (F/M)
  • USB-PS/2 Combo Console Cable Kit
  • Grounding Wire
  • Foot pads
  • Rack-Mounting Hardware
  • CD w/owner's Manual, Quick Start Guide and Device Files
  • Quick Start Guide
Country of Origin Taiwan
Environmentally Friendly Yes
Environmental Certification REACH
TAA Compliant Yes
General Information
Product Type KVM Switchbox
Manufacturer Part Number B064-016-01-IPG
Manufacturer Website Address
Manufacturer Tripp Lite
Product Model B064-016-01-IPG
Product Name B064-016-01-IPG 16-Port IP KVM Switch
Brand Name Tripp Lite
Physical Characteristics
Weight (Approximate) 7.76 lb
Form Factor Rack-mountable
Rack Height 1U
Height 1.7"
Width 17.7"
Depth 10.4"
Number of Network (RJ-45) Ports 19
Network (RJ-45) Yes
Number of USB Ports 6
PS/2 Port Yes
Number of PS/2 Ports 2
Number of VGA Ports 1
