Aten CE610A 300FT USB 2.0 DVI HDBASET KVM EXTENDER FOR CE610A

Aten

MSRP: $1,161.00
$865.00
(You save $296.00 )
UPC:
672792007163
Product Overview:

DVI HDBaseT KVM Extender with ExtremeUSB-TAA Compliant - 1 Computer(s) - 1 Remote User(s) - 328.08 ft Range - WUXGA - 1920 x 1200 Maximum Video Resolution

MFG#:
CE610A
Product Category:
KVM Accessories
Adding to cart… The item has been added

Description:

ATEN DVI HDBaseT KVM Extender with ExtremeUSB-TAA Compliant - 1 Computer(s) - 1 Remote User(s) - 328.08 ft Range - WUXGA - 1920 x 1200 Maximum Video Resolution - 2 x Network (RJ-45) - 6 x USB - 2 x DVI - 5 V DC Input Voltage - Rack-mountable - For PC, Mac, Linux

The CE610A USB DVI KVM Extender is a DVI and USB Extender that supports ExtremeUSB ® and HDBaseT technology. The CE610A can extend DVI and USB 2.0 signals up to 300 ft (100 m) from the source using a single Cat 5e/6 cable.

The CE610A is equipped with USB connectors which allow you to extend any USB device between the units. The USB functionality provides not only peripheral sharing but also the support for touch panel control and fi le transfer. The CE610A is ideal for situations where touch panel is required, such as transportation centers, medical facilities, shopping malls, industrial kiosks, and when synchronizing for files / folders between portable and desktop computers are required.

Features
  • Uses a single Cat 5e cable to connect the local and remote units
  • Allows access to a computer or KVM installation from a remote console
  • Superior Video Quality - up to 1920 x 1200 @ 60 Hz at 100 m
  • Anti-jamming - resists signal interference during high-quality video transmissions using HDBaseT technology
  • ExtremeUSB ® - supports transparent USB 2.0 signals and true plug-and-play (no software or drivers required)
  • Supports USB 1.1 web cameras
  • USB 2.0 Support* - connects devices such as keyboard, mouse, audio, flash drive, printer, touch panel other USB devices which require moderate amounts of bandwidth
  • Extends local PC Video/Keyboard/Mouse to remote side
  • Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
  • Works with all major operating systems: Windows®, OS X®, and Linux®

Specifications:

Power Description
Input Voltage 5 V DC
Power Consumption 15 W
Video
Maximum Video Resolution 1920 x 1200
Graphic Mode WUXGA
Technical Information
Connectivity Technology Wired
Maximum Operating Distance 328.08 ft
Number of Computers Supported 1
Number of Remote Users Supported 1
Interfaces/Ports
USB Yes
DVI Yes
Number of Network (RJ-45) Ports 2
Network (RJ-45) Yes
Number of USB Ports 6
Number of DVI Ports 2
Miscellaneous
Package Contents
  • 1 x CE610AL DVI HDBaseT KVM Extender with ExtremeUSB (Local Unit)
  • 1 x CE610AR DVI HDBaseT KVM Extender with ExtremeUSB (Remote Unit)
  • 1 x Custom DVI Cable (DVI Dual Link; 1.8m/6ft)
  • 1 x USB Cable (1.8m/6ft)
  • 2 x Power Adapters
  • 1 x Mounting Kit
  • 1 x User Instructions
Platform Supported PC
  Mac
  Linux
Country of Origin Taiwan
Environmentally Friendly Yes
General Information
Product Type KVM Console/Extender
Manufacturer Part Number CE610A
Manufacturer Website Address http://www.aten.com/us/en/
Manufacturer ATEN Technology, Inc
Product Model CE610A
Product Name DVI HDBaseT KVM Extender with ExtremeUSB
Brand Name ATEN
Physical Characteristics
Form Factor Rack-mountable
Transmitter Height 1.13"
Transmitter Width 4.64"
Transmitter Depth 7.17"
Receiver Height 1.13"
Receiver Width 4.64"
Receiver Depth 7.17"
Transmitter Weight (Approximate) 1.37 lb
Receiver Weight (Approximate) 1.37 lb
