Description:
The Cybex™ SC800 DPH and DPHC series secure desktop KVM switching portfolio eliminates redundant peripherals and reduces desktop clutter. This single head secure switch gives users access up to four computers using a single keyboard, monitor, and mouse. It comes with a Universal Video Connector and provides the flexibility users need in managing content from multiple computers. The DPHC models come standard with one USB-C computer connector and three traditional KVM computer connectors.
Specifications:
| # of Systems Supported | 4 |
| KVM I/O | 1 x USB-C Female 3 x DisplayPort Female 3 x HDMI Female 3 x USB-B 2.0 Female 1 x 1/8" / 3.5 mm Female |
| Console I/O | 1 x HDMI Female 1 x DisplayPort Female 2 x USB-A 2.0 Female 1 x 1/8" / 3.5 mm Audio-Out Female |
| Supported Resolutions | 3840 x 2160 @ 60 Hz |
Power
| Power Source | AC Adapter |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 0 to 80% |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
Physical
| Certifications | CE, FCC-A, RCM, TAA, TUV, VCCI *as per Manufacturer |
| Dimensions | 7 x 1.7 x 2.4" / 17.8 x 4.3 x 6.1 cm |
| Weight | 3 lb / 1.4 kg |
