HDMI KVM Extender over IP Network - 4K 30Hz HDMI and USB over IP LAN or Cat5/Cat6 Ethernet (100m/330ft)
Description:
StarTech.com HDMI KVM Extender over IP Network - 4K 30Hz HDMI and USB over IP LAN or Cat5/Cat6 Ethernet (100m/330ft) - Remote KVM Console - HDMI KVM Extender over IP transmitter & receiver kit remotely controls KVM switch/console or PC from up to 330ft/100m over Cat5e/6 Ethernet network cable/IP enabled LAN - 4K UHD 30Hz /EDID Passthrough/USB2.0 HID/ Large Signage Display or Video Wall 30HZ KVM CONSOLE EXTENDER OVER IP
This HDMI KVM extender kit lets you use a keyboard, mouse and monitor to remotely control any computer over your IP-enabled local area network (LAN). Combined with a KVM switch, the KVM console extender can be used with multiple computers. The extender features four USB ports that enable you to connect other USB devices, in addition to your keyboard and mouse.
Supports UHD 4K 30Hz
The HDMI KVM extender delivers astonishing 4K UHD picture quality to your remote display with support for resolutions up to 3840 x 2160p at 30Hz.
Hassle-Free Installation
With a transmitter and a receiver, the KVM extender provides a complete end-to-end solution that supports mounting for tidy installation. Plus, it uses standard CAT5e or CAT6 Ethernet cable, eliminating the expense and hassle of specialized cables and enabling you to use existing network infrastructure.
The extender supports EDID pass-through, ensuring your computer can automatically configure optimal settings for your display over your LAN.
Versatile Configuration Options
The extender uses your local intranet to connect your computers to your remote workstation. You can connect additional receivers (sold separately) to distribute your HDMI signal to multiple displays in your remote location, or combine the source to create a video wall that expands your single video source across multiple displays.
For smaller-scale applications, you can connect the transmitter and receiver units directly over CAT5 or CAT6 cabling up to 330 feet (100 meters).
SV565HDIP is backed by a 2-year warranty and free lifetime technical support.
Specifications:
| Limited Warranty | 2 Year |
| Maximum Video Resolution | 3840 x 2160 |
| Graphic Mode | 4K |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Consumption | 18 W |
| Input Voltage Range | 100 V AC - 240 V AC |
| Connectivity Technology | Wired |
| Maximum Operating Distance | 330 ft |
| Number of Computers Supported | 1 |
| Number of Remote Users Supported | 1 |
| Color | Black |
| Form Factor | Desktop |
| Transmitter Height | 1.10" |
| Transmitter Width | 4.60" |
| Transmitter Depth | 5.10" |
| Receiver Height | 1.10" |
| Receiver Width | 4.60" |
| Receiver Depth | 5.10" |
| Transmitter Weight (Approximate) | 1.34 lb |
| Receiver Weight (Approximate) | 1.34 lb |
| Product Type | KVM Extender |
| Manufacturer Part Number | SV565HDIP |
| Manufacturer Website Address | http://www.startech.com |
| Manufacturer | StarTech.com |
| Product Name | HDMI KVM Extender over LAN - 4K 30Hz |
| Brand Name | StarTech.com |
| USB | Yes |
| HDMI | Yes |
| Number of HDMI Ports | 2 |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Number of USB Ports | 5 |
| Package Contents |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Certification | WEEE |
| REACH | |
| RoHS | |
| TAA Compliant | Yes |
