Description:

Raritan's Dominion LX II KVM-over-IP switches give one or two remote users and one local user, Java-free, BIOS-level access and control of 8 or 16 servers (expandable to 256 servers with tiering), and virtual media. Three LX II switch models and three integrated switch / LCD drawer combination models support 8 or 16 KVM ports, 1-2 remote users, 1 local user and up to 8 serial ports. LX II appliances, designed for small to midsize businesses (SMBs), support a wide variety of computer and serial devices with VGA, DVI, HDMI, USB-C and DisplayPort video. Productive, KVM-over-IP connections up to 15 frames-per second with video resolutions up to 1080p and 1200p are supported for digital and analog video.

Specifications:

• • Type :KVM switch
  • Subcategory :KVM
  • Form Factor :Rack-mountable
  • Ports Qty :8
  • Remote Management Protocol :HTTPS, SNMP, HTTP
  • Features :IPv6 support, DHCP support, IPv4 support, KVM over IP support

• Ports

  • Qty :8
  • Type :KVM

• KVM

  • Keyboard / Mouse Interface :USB
  • KVM Local Users Qty :1
  • KVM IP Users Qty :1
  • Server Connection Via Twisted Pair :CAT5
  • KVM Max Supported Video Resolution :1920 x 1200

• Interface Provided

  • Interfaces :1 x 1000Base-T RJ-45, 1 x modem, 1 x VGA HD-15, 3 x USB 2.0 Type A, 8 x KVM RJ-45

• Power Device

  • Type :Internal power supply
  • Nominal Voltage :AC 120/230 V
  • Frequency Required :50 - 60 hertz
  • Power Consumption Operational :30 watt

• Miscellaneous

  • Color Category :Black
  • Rack Mounting Kit :Included
  • Height (Rack Units) :1
  • Encryption Algorithm :AES, TLS, FIPS 140-2
  • Authentication Method :RADIUS, LDAP, Active Directory

• Dimensions & Weight

  • Width :11.5 inch
  • Depth :10.6 inch
  • Height :1.7 inch
  • Weight :8.82 lbs

• Service & Support

  • Type :2-year warranty

• Service & Support Details

  • Service & Support :Limited warranty - 2 years

• Environmental Parameters

  • Min Operating Temperature :32 degree Fahrenheit
  • Max Operating Temperature :104 degree Fahrenheit
