ATEN KN4140VA 4 Remote & 1 Local User 40 Port Cat5
Experience unparalleled control and management of your data center with the ATEN KN4140VA KVM over IP switch. This 4th generation device offers:
- Superior Video Quality: Enjoy Full HD resolutions up to 1920 x 1200 for crystal-clear visuals.
- High-Grade Security: Complies with FIPS 140-2 level 1 security standards, ensuring your data is protected.
- Fast Virtual Media Transmission: Benefit from 2x faster speeds for seamless media access.
- Reliable Access: Dual on-board NICs and power supplies guarantee 24/7 availability.
- Out-of-Band Management: Manage network devices even when the main network is down.
- Remote Access: Connect from anywhere using Windows, Java clients, or the intuitive iOS PadClient app.
With the KN4140VA, administrators can efficiently manage their data centers, reducing travel costs and minimizing downtime.
Ports & interfaces
Number of computers controlled32
Keyboard port typeUSB, PS/2
Mouse port typeUSB, PS/2
Video port typeDVI-I
DVI-I ports quantity1
VGA (D-Sub) ports quantity1
Console portsDVI-I, RJ–45, USB A, VGA (D-Sub)
Console USB ports quantity3
USB 2.0 ports quantity3
USB connector typeUSB Type-A
USB version2.0
Serial port typeRJ-45
Serial ports quantity1
Audio connections✓
Network
Ethernet LAN✓
Ethernet LAN (RJ-45) ports2
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Security algorithms3DES, 128-bit RC4, 256-bit AES, DES, FIPS 140-2
Performance
HD typeFull HD
Maximum resolution1920 x 1200 pixels
Maximum digital resolution1920 x 1200 pixels
Data transfer rate (max)1000 Gbit/s
Scan interval1,255 s
Firmware upgradeable✓
Design
Rack mounting✓
Rack capacity1U
Product colorBlack, Gray
Housing materialMetal
Wired remote switch✓
Cascadable✓
LED indicators✓
Push button✓
Hot keys✓
Display
Built-in displayNo
Power
Power sourceAC
Input voltage100 - 240 V
AC input frequency50 / 60 Hz
Input current1 A
External power adapterNo
USB poweredNo
System requirements
Windows operating systems supported✓
Linux operating systems supported✓
Mac operating systems supported✓
Sustainability
Compliance certificatesRoHS
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Weight & dimensions
Width17.1" (433.6 mm)
Depth16.2" (412.1 mm)
Height1.73" (44 mm)
Weight12.2 lbs (5.54 kg)
Packaging content
Cables includedAC
Manual✓
Rack mount kit✓
