Aten KN4140VA 4 Remote & 1 Local user 40 Port Cat5

Aten

Regular Price $11,127.00
Discount Price: $9,175.00
UPC:
0672792403682
Product Overview:

4 Remote & 1 Local simultaneous users, 40Port Cat5 FHD IP KVM with Virtual Media and Dual Power Supply -FIPS140-2 TAA Compliant

MFG#:
KN4140VA
Product Category:
KVM Switches
Manuals Brochures and Guides:
Adding to cart… The item has been added

ATEN KN4140VA 4 Remote & 1 Local User 40 Port Cat5

Experience unparalleled control and management of your data center with the ATEN KN4140VA KVM over IP switch. This 4th generation device offers:

  • Superior Video Quality: Enjoy Full HD resolutions up to 1920 x 1200 for crystal-clear visuals.
  • High-Grade Security: Complies with FIPS 140-2 level 1 security standards, ensuring your data is protected.
  • Fast Virtual Media Transmission: Benefit from 2x faster speeds for seamless media access.
  • Reliable Access: Dual on-board NICs and power supplies guarantee 24/7 availability.
  • Out-of-Band Management: Manage network devices even when the main network is down.
  • Remote Access: Connect from anywhere using Windows, Java clients, or the intuitive iOS PadClient app.

With the KN4140VA, administrators can efficiently manage their data centers, reducing travel costs and minimizing downtime.

Ports & interfaces

Number of computers controlled32
Keyboard port typeUSB, PS/2
Mouse port typeUSB, PS/2
Video port typeDVI-I
DVI-I ports quantity1
VGA (D-Sub) ports quantity1
Console portsDVI-I, RJ–45, USB A, VGA (D-Sub)
Console USB ports quantity3
USB 2.0 ports quantity3
USB connector typeUSB Type-A
USB version2.0
Serial port typeRJ-45
Serial ports quantity1
Audio connections✓

Network

Ethernet LAN✓
Ethernet LAN (RJ-45) ports2
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Security algorithms3DES, 128-bit RC4, 256-bit AES, DES, FIPS 140-2

Performance

HD typeFull HD
Maximum resolution1920 x 1200 pixels
Maximum digital resolution1920 x 1200 pixels
Data transfer rate (max)1000 Gbit/s
Scan interval1,255 s
Firmware upgradeable✓

Design

Rack mounting✓
Rack capacity1U
Product colorBlack, Gray
Housing materialMetal
Wired remote switch✓
Cascadable✓
LED indicators✓
Push button✓
Hot keys✓

Display

Built-in displayNo

Power

Power sourceAC
Input voltage100 - 240 V
AC input frequency50 / 60 Hz
Input current1 A
External power adapterNo
USB poweredNo

System requirements

Windows operating systems supported✓
Linux operating systems supported✓
Mac operating systems supported✓

Sustainability

Compliance certificatesRoHS

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Width17.1" (433.6 mm)
Depth16.2" (412.1 mm)
Height1.73" (44 mm)
Weight12.2 lbs (5.54 kg)

Packaging content

Cables includedAC
Manual✓
Rack mount kit✓
