Tripp Lite B032-VUA4 VGA KVM SWITCH W BUILT-IN VGA USB AND 3.5 MM AUDIO CABLES 4PORT

Tripp Lite 4-Port VGA KVM Switch with Built-In VGA, USB and 3.5 mm Audio Cables - 4 Computer(s) - 1 Local User(s) - 2048 x 1536 - 4 x USB4 x VGA - TAA Compliant

Connects 4 Computers to a VGA Monitor and a Single Keyboard/Mouse

This single-monitor KVM switch lets you connect as many as four computers, which you can access and control by toggling between them. All connected computers share one VGA monitor and one USB keyboard/mouse, which saves space on your desk or workspace. Built-in four-foot (1.2-meter) VGA, USB and audio cables save you the expense and effort of buying separate cable kits for each computer. The B032-VUA4 supports video resolutions up to 2048 x 1536 (DDC2B) on a VGA monitor (P502-006-SM VGA coaxial cable sold separately).

Switching Between Computers Is Fast and Easy

Use hotkey commands or a connected mouse for quick and easy switching among computers. You can also use the Auto Scan feature to scan all connected computers automatically in five-second intervals. Port LEDs indicate which computer is currently selected. Computers may be added, removed or replaced without disconnecting or rebooting other connected computers.

Optional USB Hub Lets You Share Peripherals between Computers

Connecting an optional USB hub (sold separately) to the USB console mouse port lets you share USB peripherals, such as printers, hard drives, scanners and webcams, between all connected computers. This lets you avoid the expense and clutter of separate USB hubs.

Simple Plug-and-Play Installation and Operation

The heavy-duty metal housing can be placed on a desktop or other level surface that safely supports the weight of the KVM switch and attached cables. It requires no extra software, external power or other complicated setup procedures. It works with any computer with available VGA and USB ports (the UR024-001 USB cable is an optional accessory). It also works with gaming keyboards and wireless keyboards/mice.

Features

• Features built-in 4 ft. VGA, USB and audio cables for connecting to computers
• Hotkeys allow fast, easy toggling between connected computers
• Connect a VGA monitor with P502-006-SM cable for 2048 x 1536 (DDC2B) resolutions
• Connect USB peripherals for sharing via optional USB hub or USB cable
• Works with all major operating systems, including Windows, macOS and Linux
• 3-year limited warranty

Specifications:

Environmental Conditions Maximum Operating Temperature 122°F (50°C) Video Maximum Video Resolution 2048 x 1536 Warranty Additional Warranty Information   Limited Warranty 3 Year Interfaces/Ports USB Yes VGA Yes Number of USB Ports 4 Number of VGA Ports 4 Physical Characteristics Weight (Approximate) 1.28 lb Height 9.7" Width 38.4" Depth 37" Technical Information Features LED Indicator   Plug and Play Number of Computers Supported 4 Number of Local Users Supported 1

Miscellaneous Package Contents 4-Port VGA KVM Switch with Built-In VGA, USB and 3.5 mm Audio Cables Quick Start Guide Environmentally Friendly Yes Environmental Certification RoHS   WEEE TAA Compliant Yes General Information Product Type KVM Switchbox Manufacturer Part Number B032VUA4 Manufacturer Website Address https://tripplite.eaton.com/ Manufacturer Tripp Lite by Eaton Product Model B032-VUA4 Product Name 4-Port VGA KVM Switch with Built-In VGA, USB and 3.5 mm Audio Cables Brand Name Tripp Lite
