Raritan PX3-1243R 24-Outlets - Metered 2U - Rack-mountable

Raritan

Regular Price $1,408.00
Discount Price: $1,155.00
Shipping:
Free Shipping
MFG#:
PX3-1243R
Product Category:
PDU
Platform:
PX3
Metering and Switching:
PDU Metered
Total Outlets:
24
Plug Type:
NEMA L21-30P
Input Phase:
3 Phase Wye (Mix)
Power Capacity:
8.6 kW
Input Voltage:
208 V
Input Current:
30
Form Factor:
2U
Manufactures Website:
https://www.raritan.com
Manufactures Product Page:
https://www.raritan.com/product-selector/pdu-detail/PX3-1243R
Model or Line:
PX3
Adding to cart… The item has been added

Description:

aritan PX3-1243R 24-Outlets PDU - Metered - NEMA L21-30P - 9 x IEC 60320 C13, 3 x IEC 60320 C19, 12 x NEMA 5-20R - 230 V AC - Network (RJ-45) - 9.84 ft Cord Length - 2U - Rack-mountable

Features
  • PDU improves efficiency, uptime and growth of data centers
  • Monitor load level efficiently with PDU meter
  • Three Phase phase PDU for reliable performance with maximum productivity
  • NEMA L21-30P plug/connector type for reliable, productive connectivity and optimal power output
  • IEC 60320 C13 receptacle type to ensure maximum dependability and optimal performance
  • 230 V AC input voltage for better reliance and maximum dependability
  • 240 V AC output voltage for better reliance and maximum usability

Specifications:
Interfaces/Ports
Network (RJ-45) Yes
Management
Remote Outlet Switching No
Environmental Conditions
Maximum Operating Temperature 140°F (60°C)
Maximum Operating Humidity 85%
Physical Characteristics
Weight (Approximate) 33.07 lb
Mount Type Rack-mountable
Rack Height 2U
Cord Length 9.84 ft
Power Description
Circuit Breaker No
Input Voltage 230 V AC
  230 V AC
Output Voltage 240 V AC
  240 V AC
Input Current 30 A
Power Rating (VA) 8600 VA
General Information
Product Type PDU
Manufacturer Part Number PX31243R
Manufacturer Website Address http://www.legrand.us
Manufacturer Legrand Group
Product Model PX3-1243R
Product Name PX3-1243R 24-Outlets PDU
Product Series PX3
Brand Name Raritan
Technical Information
Features Onboard Display
  LCD Display
Plug/Connector Type NEMA L21-30P
Phase Three Phase
Receptacle Type NEMA 5-20R
  IEC 60320 C19
  IEC 60320 C13
PDU Type Metered
  Metered
Environmental Sensors Air Flow
  Differential Pressure
  Contact Closure
  Water
  Dust
  Humidity
  Temperature
Receptacle Detail 9 x IEC 60320 C13
  3 x IEC 60320 C19
  12 x NEMA 5-20R
