Server Technology C2WG24SN-4NJN5D6 PRO2 PDU 400 Volt 24 Outlets 2U

Server Technology

Regular Price $2,699.00
Discount Price: $2,294.00
Shipping:
Free Shipping
MFG#:
C2WG24SN-4NJN5D6
Product Category:
PDU
Platform:
PRO2
Metering and Switching:
Switched POPS
Total Outlets:
24
Plug Type:
230/400V Wye 16A IEC 60309 3P+N+PE 6Hr
Input Phase:
3 Phase Wye (L-N)
Power Capacity:
11 kW
Input Voltage:
400 V
Input Monitoring:
PIPS
Input Current:
16
Input Current Rating:
16
Form Factor:
2U
Rack Mounting Style:
Horizontal
Branch Monitoring:
Current (A)
Alt Phase:
FALSE
Adding to cart… The item has been added

Description:

The Server Technology® PRO2 Switched POPS PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® and POPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input and at each output. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Switched POPS "Primary" PDU can be connected to as many as three (with optional module) PRO2 Switched POPS "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.

  • HDOT CX: Cx is the future ready UL tested hybrid of the C13 and C19 outlets accommodating both C20 and C14 plugs.
  • NETWORK MONITORING: Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more.
  • HOT-SWAP NETWORK CARD: Network access is ensured when power is lost to the Primary unit with backup power provided by the primary link unit.
  • STAR MULTI-LINKING: Provides the ability to link up to four power circuits using one IP address. Primary link provides backup power to network card.
  • TEMPERATURE/HUMIDITY MONITORING: Primary and Link units each support two external 10' (3m) T/H probes. Receive SNMP-based alerts and email notifications.
  • AUTO-FLIP CURRENT DISPLAY: Easy-to-read LEDs display current per phase to help prevent overloads and simplify three-phase load balancing in high-density cabinets.
  • PER-INLET POWER SENSING: Meets ANSI C12.1 for billing-grade accuracy of Current per phase. PIPS includes voltage, active power, apparent power, power factor, and energy.
  • PER-OUTLET POWER SENSING: Meets ANSI C12.1 for billing-grade accuracy of Current per phase. POPS includes voltage, active power, apparent power, power factor, and energy.
  • BRANCH CURRENT MONITORING: PRO2 monitors current at each breaker branch and provides SNMP-based alerts and emails on high usage that risks a tripped circuit.
  • BRANCH CIRCUIT PROTECTION: This PDU meets the UL and IEC 60950-1 requirement for branch circuit protection through use of UL489 rated magnetic-hydraulic circuit breakers or UL248 fuses.

Specifications:

Interfaces/Ports
Network (RJ-45)Yes
Management
Management
  • HTTP/HTTPS
  • TLSv1.2
  • SSHv2
  • Telnet
  • SNMPv2c
  • IPv4
  • IPv6
  • LDAPv3/LDAPS
  • TACACS+
  • RADIUS
  • FTP/SFTP
v3:
  • GET
  • SET
  • Traps
Power Description
Input Current16 A
Power Rating (Watt)11 kW
Physical Characteristics
Height3.5"
Width17.2"
Depth17.5"
Miscellaneous
Package Contents
  • Switched POPS PDU - 11.0kW, C2WG24SN-4NJN5D6
  • Button Mounts
Country of OriginTaiwan
Environmentally FriendlyYes
Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE)
Restriction of Hazardous Substances (RoHS)
General Information
Product TypePDU
Manufacturer Part NumberC2WG24SN-4NJN5D6
Manufacturer Website Addresshttp://www.servertech.com
ManufacturerServer Technology, Inc
Product ModelC2WG24SN-4NJN5D6
Product NameSwitched POPS PDU - 11.0kW, C2WG24SN-4NJN5D6
Product SeriesPRO2
Brand NameServer Technology
Technical Information
Protection TypeBranch Circuit
Overload Protection
Single Pole
Plug/Connector TypeIEC 60309 3P+N+PE 6Hr 16A
PhaseThree Phase
Environmental SensorsTemperature
Humidity
Receptacle Detail18 x IEC 60320 C13
6 x CX
