Description:
Raritan SMART IN-LINE METER 230/400V 16A IEC 60309 3P+N+PE 6HR
Specifications:
Features
• Energy Metering: Voltage (V), Current (A), Active Power (kW), Real Power (kVA), Energy (kWh), Power Factor
• Metering Accuracy: ISO/IEC 62053-21 1%
• Metering per input line
• Environmental Sensor Ready
• Compatible Sensors: Temperature, Humidity, Air Flow, Differential Pressure, Water Leak, and Contact Closure.
• Cascading: Max 16 PDUs can be daisy chained using a USB or Ethernet connection.
• Networking: (10/100/1000 Base T) Ethernet, Secondary redundant (10/100/1000 Base T) Ethernet. Optional WiFi (802.11 a/b/g/n).
• Onboard Display: Colour, matrix LCD display : Voltage, current, or active power (per line); Alarms; Configuration information (name, ratings, IP / Networking information).
Specifications
Input
• Input Plug: IEC 60309 3P+N+E 6h 16A (4P5W)
• Nominal Voltage: 400V
• Maximum Input Current: 16A
• Rated Input Current: 16A
• Power Capacity: 0kVA
• Cord Length: 3m
Output
• Nominal Voltage: 400V
• Receptacles (Output Connections)
(1) x IEC309 3P+N+E 6h 16A
Physical
• Dimensions (WxDxH): 52mm x 65mm x 439mm
• Unit Weight: 2.6 kg
• Shipping Weight: 4.1 kg
• Shipping Dimensions: 230mm x 113mm x 1140mm
• Mounting: G2-RACK-FOR-ZU
