Description:
he VS1818T HDMI over single Cat 5 Splitter provides a fast and efficient way of switching high definition video from one input source to 8 displays. Incorporating suggested HDBaseT receivers*, the VS1818T can be a complete solution ideal for any installation that requires HDMI content to be delivered to multiple destinations, located up to 100m away from the source.
* Suggested Compatible Receiver Units: VE812R HDMI Over Single Cat 5 Receiver
The solution implements HDBaseT extension technology to connect the VS1818T to receiver units over one single Cat 6 cable in order to transmit rich HDMI multimedia content in real time. It supports up to 4k2k resolution, and features an EDID selection method to ensure constant and reliable EDID data relay for the HDMI source device to efficiently optimize video resolution.
The VS1818T solution is perfect for a wide range of applications:
- In-store or tradeshow digital signage
- Information broadcasts at public locations (i.e., news, stations, airline and train schedule and arrival/departure details)
- Sporting events
- Theater and lecture overview rooms
- Classroom and company training facilities
Specifications:
| Product Type: |
Video Extender Receiver |
| Color: |
Black |
| Connectivity Technology: |
Wired |
| Form Factor: |
Rack-mountable |
| Brand Name: |
VanCryst |
| Maximum Operating Distance: |
328.08 ft |
| Number of Network (RJ-45) Ports: |
8 |
| Number of HDMI Inputs: |
1 |
| Number of Output Devices Supported: |
8 |
| Number of Input Devices Supported: |
1 |
| General Information |
|---|
| Product Type: |
Video Extender Receiver |
| Manufacturer Part Number: |
VS1818T |
| Manufacturer Website Address: |
http://www.aten-usa.com |
| Manufacturer: |
ATEN Technology Inc |
| Product Model: |
VS1818T |
| Product Name: |
8-Port HDMI Over Single Cat 5 Splitter |
| Brand Name: |
VanCryst |
| Interfaces/Ports |
|---|
| Number of Network (RJ-45) Ports: |
8 |
| Network (RJ-45): |
Yes |
| Serial Port: |
Yes |
| Number of HDMI Inputs: |
1 |
| Number of HDMI Outputs: |
1 |
| HDMI In: |
Yes |
| HDMI Out: |
Yes |
| Miscellaneous |
|---|
| Package Contents: |
- VS1818T 8-Port HDMI Over Single Cat 5 Splitter
- 1 x Power Cord
- 1 x Mounting Kit
- 1 x User Instructions
|
| Environmentally Friendly: |
Yes |
| Environmental Certification: |
WEEE |
|
RoHS |
| Physical Characteristics |
|---|
| Material: |
Metal |
| Color: |
Black |
| Form Factor: |
Rack-mountable |
| Receiver Height: |
1.73" |
| Receiver Width: |
10.28" |
| Receiver Depth: |
17.21" |
| Receiver Weight (Approximate): |
7.89 lb |
| Power Description |
|---|
| Input Voltage: |
230 V AC |
|
120 V AC |
| Technical Information |
|---|
| Connectivity Technology: |
Wired |
| Maximum Operating Distance: |
328.08 ft |
| Number of Output Devices Supported: |
8 |
| Number of Input Devices Supported: |
1 |
| Video |
|---|
| Graphics Modes: |
4K |
| Maximum Video Resolution: |
4096 x 2160 |
