Aten CE924 USB DisplayPort HDBaseT 2.0 KVM Extender

Aten CE924 USB DisplayPort HDBaseT 2.0 KVM Extender

Aten

Regular Price $1,873.00
Discount Price: $1,328.00
UPC:
672792012426
Product Overview:

USB DisplayPort Dual Display HDBaseT 2.0 KVM Extender (Single Display up to 4K / Dual Display up to 1080P)

MFG#:
CE924
Product Category:
KVM Accessories
Adding to cart… The item has been added

Description

ATEN USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (4K@100m for Single View) - 2 Computer(s) - 2 Local User(s) - 328.08 ft Range - 4K - 4096 x 2160 Maximum Video Resolution - 2 x Network (RJ-45) - 5 x USB - DisplayPort - Rack-mountable KVM EXTENDER

The ATEN CE924 USB DisplayPort Dual View HDBaseT™ 2.0 KVM Extender integrates the latest HDBaseT™ 2.0 technologies to deliver 4K video, stereo audio, USB, and RS-232 signals. The HDBaseT™ 2.0 guarantees the most reliable transmission on the market as well as it provides long-reach capability that extends Full HD 1080P signals up to 500 feet. In addition, CE924 supports single 4K display or dual 1080p display for DisplayPort video output resolution up to 100m by using a single Cat6 / 2L-2910 Cat 6 cable.

With an easy cable installation supporting various signals, the CE924 is ideal for applications where convenient remote access is required - such as transportation control centers, medical facilities, industrial warehouses, and extended workstations.

Video
Maximum Video Resolution 4096 x 2160
Graphic Mode 4K
Interfaces/Ports
USB Yes
Number of Network (RJ-45) Ports 2
Network (RJ-45) Yes
Number of USB Ports 5
DisplayPort Yes
Technical Information
Connectivity Technology Wired
Maximum Operating Distance 328.08 ft
Number of Computers Supported 2
Number of Local Users Supported 2
Device Type KVM Extender
Miscellaneous
Package Contents
  • 1 x CE924L USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (Local Unit)
  • 1 x CE924R USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (Remote Unit)
  • 2 x DisplayPort cables
  • 1 x Pink audio jack cable set
  • 1 x Green audio jack cable set
  • 1 x USB Type-A to Type-B cable
  • 2 x Power adapters
  • 2 x Mounting kits
  • 1 x User instructions
Certifications & Standards
    • CE
    • FCC
Environmentally Friendly Yes
Environmental Certification WEEE
RoHS
China RoHS
General Information
Product Type KVM Extender
Manufacturer Part Number CE924

Manufacturer ATEN Technology, Inc
Product Model CE924
Product Name USB DisplayPort Dual View HDBaseT 2.0 KVM Extender (4K@100m for Single View)
Brand Name ATEN
Physical Characteristics
Form Factor Rack-mountable
Transmitter Height 1.13"
Transmitter Width 6.07"
Transmitter Depth 6.86"
Receiver Height 1.13"
Receiver Width 6.13"
Receiver Depth 6.86"
Transmitter Weight (Approximate) 1.81 lb
Receiver Weight (Approximate) 1.87 lb
!
