Description:
The ATEN VP1920 is a 3-in-1 presentation switch that integrates a video matrix switch, an audio processor, and analog-to-digital converter functions. With nine multi-format inputs to two HDMI 4K outputs, it is designed to boost the efficiency and impact of professional presentations. With streamlined control from front panel pushbuttons, IR remote controller, OSD, and RS-232, the VP1920 reduces not only system device count, but also lower operation complexity. It is suitable for all small-to-medium sized corporate and education presentation environments, such as meeting rooms, classrooms, training rooms, or any other presentation setting, such as in exhibition centers or hotels
Specifications:
| Product Type: |
Audio/Video Switchbox |
| Device Supported: |
Set-top Box |
|
Blu-ray Disc Player |
|
Display |
|
Media Center |
| Connectivity Technology: |
Cable |
| Form Factor: |
Desktop |
| Brand Name: |
Aten |
| Maximum Operating Distance: |
49.21 ft |
| DisplayPort: |
Yes |
| Number of HDMI Inputs: |
6 |
| VGA In: |
Yes |
| HDMI In: |
Yes |
| HDMI Out: |
Yes |
| Number of Displays Supported: |
2 |
| Number of Input Devices Supported: |
9 |
| Number of VGA Inputs: |
1 |
| General Information |
|---|
| Product Type: |
Audio/Video Switchbox |
| Manufacturer Part Number: |
VP1920 |
| Manufacturer Website Address: |
http://www.aten.com/us/en/ |
| Packaged Quantity: |
1 |
| Manufacturer: |
ATEN Technology, Inc |
| Product Model: |
VP1920 |
| Product Name: |
9 x 2 4K Presentation Matrix Switch |
| Brand Name: |
Aten |
| Interfaces/Ports |
|---|
| Number of USB Ports: |
6 |
| DisplayPort: |
Yes |
| Number of HDMI Inputs: |
6 |
| Number of HDMI Outputs: |
2 |
| VGA In: |
Yes |
| HDMI In: |
Yes |
| HDMI Out: |
Yes |
| Number of VGA Inputs: |
1 |
| Number of DisplayPort Inputs: |
1 |
| Media & Performance |
|---|
| Maximum Operating Distance: |
49.21 ft |
| Miscellaneous |
|---|
| Package Contents: |
- 9 x 2 4K Presentation Matrix Switch
- 1 x Power Cord
- 1 x IR Receiver
- 1 x IR Remote Control
- 1 x User Instructions
|
| Environmentally Friendly: |
Yes |
| Environmental Certification: |
RoHS |
|
WEEE |
| Physical Characteristics |
|---|
| Weight (Approximate): |
5.20 lb |
| Form Factor: |
Desktop |
| Height: |
1.7" |
| Width: |
17.2" |
| Depth: |
6.4" |
| Technical Information |
|---|
| Device Supported: |
Media Center |
|
Set-top Box |
|
Display |
|
Blu-ray Disc Player |
| Connectivity Technology: |
Cable |
| Number of Displays Supported: |
2 |
| Number of Input Devices Supported: |
9 |
| Video |
|---|
| Graphics Modes: |
4K |
| Maximum Video Resolution: |
4096 x 2160 |
