Number of computers controlled16

Keyboard port typeUSB, PS/2

Mouse port typeUSB, PS/2

Video port typeDVI-D

DVI-D ports quantity1

VGA (D-Sub) ports quantity1

Console portsDVI-D, USB A, VGA (D-Sub)

Console USB ports quantity2

USB 2.0 ports quantity3

USB connector typeMini-USB

Audio connections✓

Headphone outputs1

Number of microphone inputs1

DC-in jack✓

Ethernet LAN✓

Ethernet LAN (RJ-45) ports20

Cabling technology10/100/1000Base-T(X)

Security algorithmsFIPS 140-2

Maximum resolution1920 x 1200 pixels

Scan interval255 s

Rack mounting✓

Rack capacity1U

Product colorMetallic

Housing materialMetal

LED indicatorsLink, Power

Push button✓

Hot keysNo

Built-in displayNo

Input voltage100-240 V

AC input frequency50 - 60 Hz

Input current1 A

Power consumption (typical)49.06 W

Operating temperature (T-T)0 - 40 °C

Storage temperature (T-T)-20 - 60 °C

Operating relative humidity (H-H)0 - 80%

Width17.1" (433.6 mm)

Depth16.2" (412.1 mm)

Height1.73" (44 mm)

Weight12.3 lbs (5.6 kg)

Harmonized System (HS) code85176200
