Description:

This is an MSA compliant 200GBase-AOC QSFP56 to 2xQSFP56 active optical cable that operates over multi-mode fiber with a maximum reach of 20.0m (65.6ft). At a wavelength of 850nm, it has been programmed, uniquely serialized, and data-traffic and application tested to ensure it is 100% compliant and functional. This active optical cable is TAA (Trade Agreements Act) compliant, and is built to comply with MSA (Multi-Source Agreement) standards. We stand behind the quality of our products and proudly offer a limited lifetime warranty.

• Low latency DSP-free electronics-based CDR
• Multi-data rate up to 56.15 Gb/s per lane
• PAM4 modulation
• Single 3.3 V power supply
• Low power consumption: 3.6W on 200G end with all CDRs enabled
• Up to 20m length
• SFF-8665 compliant
• SFF-8636 compliant I2C management interface
• Operating case temperature: 0◦C to 70◦C
• Hot pluggable

Specifications:

Description:

This is an MSA compliant 200GBase-AOC QSFP56 to 2xQSFP56 active optical cable that operates over multi-mode fiber with a maximum reach of 20.0m (65.6ft). At a wavelength of 850nm, it has been programmed, uniquely serialized, and data-traffic and application tested to ensure it is 100% compliant and functional. This active optical cable is TAA (Trade Agreements Act) compliant, and is built to comply with MSA (Multi-Source Agreement) standards. We stand behind the quality of our products and proudly offer a limited lifetime warranty.

• Low latency DSP-free electronics-based CDR
• Multi-data rate up to 56.15 Gb/s per lane
• PAM4 modulation
• Single 3.3 V power supply
• Low power consumption: 3.6W on 200G end with all CDRs enabled
• Up to 20m length
• SFF-8665 compliant
• SFF-8636 compliant I2C management interface
• Operating case temperature: 0◦C to 70◦C
• Hot pluggable

Specifications:
