Description:
Vertiv Liebert GXT5 UPS - 4900VA/4600W 208V | Online Rack Tower Energy Star - Double Conversion| 5U| Built-in RDU101 Card| Color/Graphic LCD| 3-Year Warranty
The Vertiv Liebert GXT5 uninterruptible power supply (UPS) protects critical equipment against outages and every type of power disturbance. This 4900VA online double conversion UPS offers continuous power conditioning in centralized and edge locations. With high power factor (0.9-1.0), it allows more connected loads saving space and costs. This tower/rack mount UPS has an optional Vertiv RDU101 communications card for remote monitoring to help you make more informed decisions and faster event resolution. With the free Vertiv Power Insight software, you can consolidate your view of up to 100 distributed UPS units providing simple notification of status and events in a single pane of glass. This 208V in/ 208V out single phase UPS has scalable runtime options with matching external battery cabinets to give extra runtime during an outage to support critical equipment. This battery backup is ENERGY STAR 2.0 certified and comes with an intuitive gravity sensing full-color LCD display.
Features
- HIGH POWER FACTOR (0.9-1.0): More usable power allows more connected loads saving space and costs.
- REMOTE MANAGEMENT: Optional Vertiv RDU101 network communications card with advanced features.
- 3-YEAR WARRANTY: 3-year comprehensive coverage including battery with options for 2-year extension.
- ENERGY EFFICIENT (up to 95%): Energy Star 2.0 certified with high normal operating efficiency.
- EASY-TO-USE INTERFACE: Tower/rack mount design with gravity sensing graphical color display.
Specifications:
Controls/Indicators |
Status Indicators |
LED/Full Color Graphic LCD:
|
Warranty |
Limited Warranty |
3 Year |
Physical Characteristics |
Form Factor |
Rack/Tower |
Rack Height |
5U |
Environmental Conditions |
Environmental Sensors |
Leak Detection Sensor |
|
Humidity Sensor |
|
Temperature Sensor |
Interfaces/Ports |
USB |
Yes |
VGA |
No |
Network (RJ-45) |
Yes |
Modem (RJ-11) |
No |
Serial Port |
Yes |
Total Number of Expansion Slots |
1 |
Miscellaneous |
Additional Information |
- Package Type: Natrual corrugated with single color silk screen
- Dataline Protection: No
- Product Shipping Length: 25.4"
- Product Shipping Width: 32.1"
- Product Shipping Height: 20.5"
- Product Shipping Weight: 202.8 lbs
|
Package Contents |
- GXT5 6k L630 UPS
- 4 Post Fixed Rail Kit
- Tower Stand
- USB Cable
- Quick Start Guide
- Safety Instruction Manual
|
Country of Origin |
China |
Environmentally Friendly |
Yes |
TAA Compliant |
No |
Energy Star |
Yes |
Power Description |
Input Voltage |
230 V AC |
Output Voltage |
208 V AC |
Load Capacity |
4900 VA/4900 W |
Waveform Type |
Pure Sine Wave |
Input Frequency |
50 Hz |
Utility (AC) Mode Overload |
- 105% to 125% for 5 minutes
- 125% to 150% for 60 seconds
- >150% (impact load) minimum 200 ms
|
|
Battery Information |
Battery Chemistry |
Lead Acid |
Hot Swappable |
Yes |
Backup/Run Time (Half Load) |
14.50 Minute |
Backup/Run Time (Full Load) |
5.50 Minute |
Battery Characteristics |
Valve-regulated |
Number of External Battery Cabinets |
1 |
Backup/Run Time With External Battery Cabinet (Full Load) |
9.50 Minute |
Backup/Run Time With External Battery Cabinet (Half Load) |
25.50 Minute |
General Information |
Product Type |
Double Conversion Online UPS |
Manufacturer Part Number |
GXT5-6KL630RT5UXLN |
Manufacturer Website Address |
http://www.vertiv.com/ |
Packaged Quantity |
1 |
Manufacturer |
Vertiv |
Product Name |
GXT5 6k L630 UPS |
Product Series |
GXT |
Brand Name |
Liebert |
Technical Information |
Application/Usage |
Data Center |
|
Mission Critical Equipment |
Bypass Switch |
Maintenance |
|
Automatic & Manual |
|
Internal |
Emergency Power OFF |
Yes |
Plug/Connector Type |
Hardwired |
Phase |
Single Phase |
Receptacle Type |
Hardwired |
|
IEC 60320 C19 |
|
IEC 60320 C13 |
Transfer Time |
0 ns |
Receptacle Detail |
2 x IEC 60320 C19 |
|
6 x IEC 60320 C13 |
|
