Vertiv Geist RTS VA4N2100 - Rack Transfer Switch| RPDU| (10) NEMA 5-20R - Unit Level Monitored 1U

Vertiv

Regular Price $1,927.00
Discount Price: $1,196.00
MFG#:
VA4N2100
Product Category:
PDU
Total Outlets:
20
Form Factor:
1U
Rack Mounting Style:
Horizontal
Adding to cart… The item has been added

Description:

The Vertiv Geist Rack Transfer Switch VA4N2100 is a versatile rack power distribution unit (rPDU) with a transfer switch. It is a 20A, 120V, single phase rack PDU with 10 NEMA 5-20R outlets and a max power capacity of 1.9kW. The RTS provides redundant power to single corded devices and helps ensure continuity in the event of power loss. It can quickly detect power loss on the main source and automatically switch it to the secondary source within 4 to 8 milliseconds. The Interchangeable Monitoring Device provides unit level remote power monitoring, as well as environmental monitoring capabilities with the addition of optional sensors. This TAA-Compliant Vertiv RTS comes with a standard three-year warranty, which can be extended to five years if registered within 120 days after purchase.

The Vertiv Geist Rack Transfer Switch VA4N2100 is a versatile rack power distribution unit (rPDU) with a transfer switch. It is a 20A, 120V, single phase rack PDU with 10 NEMA 5-20R outlets and a max power capacity of 1.9kW. The RTS provides redundant power to single corded devices and helps ensure continuity in the event of power loss. It can quickly detect power loss on the main source and automatically switch it to the secondary source within 4 to 8 milliseconds. The Interchangeable Monitoring Device provides unit level remote power monitoring, as well as environmental monitoring capabilities with the addition of optional sensors. This TAA-Compliant Vertiv RTS comes with a standard three-year warranty, which can be extended to five years if registered within 120 days after purchase.

Specifications:

Management
  • DHCP
  • HTTP
  • HTTPS
  • IPv4
  • IPv6
  • LDAP
  • NTP
  • RADIUS
  • RSTP
  • SSH
  • SMTP
  • SNMP (v1/v2c/v3)
  • Modbus TCP/IP
  • Syslog
  • TACACS+
Remote Outlet SwitchingNo
Input Voltage120 V
Input Current20 A
Input Voltage Range100 V AC - 120 V AC
Output Voltage Range100 V AC - 120 V AC
Power Rating (Watt)1900 W
USBYes
Network (RJ-45)Yes
Modem (RJ-11)No
Serial PortYes
Modem (RJ-12)Yes
Modem (RJ-22)No
Certifications & Standards
  • UL
  • c-UL Listed 62368
Country of OriginUnited States
Environmentally FriendlyYes
TAA CompliantYes
Environmental ComplianceChina Restriction of Hazardous Substances (China RoHS)
Restriction of Hazardous Substances (RoHS)
Plug/Connector TypeNEMA 5-20P
PhaseSingle Phase
Receptacle TypeNEMA 5-20R
PDU TypeSwitched Auto Transfer Switch
Receptacle Detail10 x NEMA 5-20R
Plug/Connector Detail2 x NEMA 5-20P
Product TypePDU
Manufacturer Part NumberVA4N2100
Manufacturer Website Addresshttp://www.vertiv.com/
ManufacturerVertiv
Product ModelAN03E1R5-10S203-2ST5ST5A011-D
Product NameGU VA4N2100 PDU
Product SeriesN
Brand NameGeist
Weight (Approximate)19 lb
Rack Height1U
Height1.7"
Width17"
Depth18"
Number of Cord/Cable2
Mounting OrientationHorizontal
Product ColorBlack
