Description
Vertiv Cybex SC900 Secure KVM | Dual Head | 4 Port Universal DisplayPort | NIAP version 4.0 Certified - Secure Desktop KVM Switches | Secure KVM Switch | Dual Head | NIAP Certified | Secure Keyboard | 2 to 8 Port, Secure Isolated Channels | Running up to UHD 4K at 60Hz | 3-Year Full Coverage Factory Warranty - Optional Extended Warranty Available
The Vertiv Cybex SC900 series secure desktop KVM switching portfolio offers a proven solution for guarding against desktop cyber intrusion while working efficiently and with a minimum of clutter. These switches enable users to seamlessly and securely switch between multiple computer resources at the push of a button. Certified to meet the recently released NIAP Common Criteria Protection Profile for Peripheral Sharing Devices (PSD) ver. 4.0, the Vertiv Cybex KVM switches provide high resolution compatibility up to UHD 4K at 60Hz. The Vertiv Cybex SC900 series models are available in single-head and dual-head two-port, four-port, and eight-port options, with the DPHC models coming with a USB-C connection. With a universal port on every unit, the Vertiv Cybex SC900 can use a combination of DP, HDMI, or VDI-D cables without needing additional adaptors.
Specifications:
| Physical | |
| Height | 2.2 in (56 mm) |
| Width | 13.7 in (348 mm) |
| Depth | 5.0 in (127 mm) |
| Weight | 3.7 lbs (1.9 kg) |
| Mounting Options | Desk Mount - DMK-09 |
| Computers | |
| Ports | 4 |
| DP/HDMI Univ Video (1) | 2 |
| MAX Resolution | UHD 4K (3840x2160) @ 60Hz |
| Keyboard and Mouse | 1 x USB 2.0 Type B |
| DPP - USB 2.0 Type B | 0 |
| Analog Audio | 1 x 3.5mm Speaker |
| Console | |
| DP/HDMI Univ Video | 2 |
| Keyboard and Mouse | 2 x USB 2.0 Type A |
| DPP - USB 2.0 Type A | 0 |
| Analog Audio | 1 x 3.5mm Speaker |
| Environmental | |
| Operating Temperature | 0 to 40C / 32 to 104 F |
| Storage Temperature | -20 to 60C / -4 to 140 F |
| Humidity | 0 to 80% RH, non-condensing |
| Power | |
| AC Input Voltage | 100 to 240V AC |
| Power Supplies | 1 x external, 2.5A Max |
| Power Connector | Wall-mounted power supply with user-interchangeable localized plug blades |
| Regulatory | |
| Security Evaluation | Designed for Common Criteria Protection Profile for Peripheral Sharing Device v. 4.0 and Evaluation Assurance Level (EAL) 4+ |
| Regulatory Certifications | FCC class A, CE, TUV US, TUV Canada, RCM, VCCI |
| Standard Product Warranty | 3 Years; additional warranty terms available |
| Design & Assembly | Huntsville, AL USA |
