Tripp Lite B002-HD1AC4 4-Port KVM Switch - Secure HDMI to DisplayPort
The Tripp Lite B002-HD1AC4 is a state-of-the-art 4-Port KVM switch designed for environments that require the highest level of data security, such as government, military, financial, and healthcare sectors. This KVM switch allows you to control up to four computers from a single monitor, keyboard, and mouse setup, ensuring seamless operation without compromising sensitive information.
Key Features:
- NIAP PP3.0 Certified: Meets stringent information assurance standards to prevent data leakage and crosstalk.
- Top-of-the-Line Security: Features anti-tampering protection and automatic keyboard buffer clearing to safeguard your data.
- CAC Port: Supports biometric and smart card readers for enhanced user authentication.
- Constant Emulation: Maintains keyboard and mouse emulation for smooth, no-delay switching.
- TAA-Compliant: Eligible for GSA Schedule and federal procurement contracts.
With its robust security features and high-resolution support of up to 3840 x 2160 (4K x 2K) at 30 Hz, the Tripp Lite B002-HD1AC4 is the ideal solution for protecting sensitive data while ensuring efficient multi-computer management.
Ports & interfaces
Number of computers controlled4
Keyboard port typeUSB
Mouse port typeUSB
Video port typeDisplayPort
HDMI ports quantity1
HDMI version1.4
DisplayPorts quantity4
USB 2.0 Type-B ports quantity8
Console portsHDMI, USB A
Console USB ports quantity3
Audio connections✓
Headphone outputs5
DC-in jack✓
Performance
HD type4K Ultra HD
Maximum resolution3840 x 2160 pixels
Video bandwidth30 Hz
Number of users1 user(s)
Design
Rack mountingNo
Product colorBlack
Cable length59.1" (1.5 m)
LED indicators✓
Push button✓
Display
Built-in displayNo
Power
Power sourceAC
Input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current0.8 A
Output voltage12 V
Output current2 A
External power adapter✓
System requirements
Windows operating systems supported✓
Linux operating systems supported✓
Mac operating systems supported✓
Sustainability
Compliance certificatesRoHS
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Storage relative humidity (H-H)0 - 80%
Weight & dimensions
Width12.6" (319.3 mm)
Depth6.7" (170.2 mm)
Height1.76" (44.7 mm)
Weight2.45 lbs (1.11 kg)
Packaging data
Package width11.1" (282.6 mm)
Package depth15.1" (384.2 mm)
Package height4" (101.6 mm)
Package weight3.99 lbs (1.81 kg)
Package typeBox
Packaging content
Cables includedAC
Manual✓
AC adapter included✓
Logistics data
Harmonized System (HS) code8471.80.4000
Master (outer) case width18" (457.2 mm)
Master (outer) case length24" (609.6 mm)
Master (outer) case height18" (457.2 mm)
Master (outer) case weight48.1 lbs (21.8 kg)
Quantity per master (outer) case8 pc(s)
Master (outer) case GTIN (EAN/UPC)10037332221978
Country of originUnited States
