Tripp Lite B002-H2A4-N4 4-Port HDMI KVM Switch - Secure Data Management

Tripp Lite

Regular Price $1,672.00
Discount Price: $930.00
UPC:
37332274373
MFG#:
B002-H2A4-N4
Product Category:
KVM Switches
Manuals Brochures and Guides:
Adding to cart… The item has been added

Tripp Lite B002-H2A4-N4 4-Port HDMI KVM Switch

Secure Data Management for Sensitive Environments
This 4-Port HDMI KVM Switch is designed for applications that require stringent security measures, making it ideal for government, military, finance, education, and healthcare sectors. With electronically isolated channels for each KVM port, it ensures that data cannot be transferred between connected computers, even if they operate at different security levels.

NIAP PP4.0 Certified
Certified by the National Information Assurance Partnership (NIAP) to meet the latest Common Criteria Protection Profile for Peripheral Sharing Switches Version 4.0, this KVM switch features discrete processing paths to prevent data leakage and crosstalk between ports.

Advanced Security Features
With special firmware protection and automatic keyboard buffer clearing, your data remains secure. Access to connected computers is restricted to the switch’s panel buttons, eliminating risks associated with on-screen displays or hotkey commands.

Anti-Tampering Protection
Internal anti-tamper switches disable the unit if the housing is opened, providing visual evidence of tampering.

Seamless Switching Experience
Enjoy smooth, no-delay switching with constant keyboard and mouse emulation. The KVM switch supports secure video emulation and EDID learning, preventing unwanted data transmission through DDC lines.

TAA-Compliant
The B002-H2A4-N4 is compliant with the Federal Trade Agreements Act (TAA), making it eligible for GSA Schedule purchases.

Ports & interfaces

Number of computers controlled4
Keyboard port typeUSB
Mouse port typeUSB
Video port typeHDMI
HDMI ports quantity10
USB 2.0 Type-B ports quantity4
Console ports3.5mm headphone, HDMI, USB A
Console USB ports quantity2
USB connector typeUSB Type-A, USB Type-B
Audio connections✓
Headphone outputs4
DC-in jack✓

Performance

HD type4K Ultra HD
Maximum resolution3840 x 2160 pixels
Video bandwidth60 Hz
Number of users1 user(s)

Design

Rack mountingNo
Product colorBlack
Housing materialMetal
Cable length59.1" (1.5 m)
LED indicators✓
Push button✓
CertificationCE; UKCA; cUL, NOM (Mexico), NIAP PP4.0; RoHS; CE (Europe); UKCA; FCC (USA)

Display

Built-in displayNo

Power

Power sourceDC
Input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current1.3 A
Output voltage12 V
Output current3 A
External power adapter✓

System requirements

Windows operating systems supported✓
Linux operating systems supported✓
Mac operating systems supported✓

Sustainability

Compliance certificatesCE, Federal Communications Commission (FCC), RoHS, UKCA

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Storage relative humidity (H-H)0 - 80%

Weight & dimensions

Width12.5" (317 mm)
Depth6.65" (169 mm)
Height2.7" (68.5 mm)
Weight4.21 lbs (1.91 kg)

Packaging data

Package width11" (279.4 mm)
Package depth16" (406.4 mm)
Package height4" (101.6 mm)
Package weight6 lbs (2.72 kg)
Package typeBox

Packaging content

Cables includedDC
Manual✓

Logistics data

Harmonized System (HS) code8471.80.4000
Master (outer) case width19" (482.6 mm)
Master (outer) case length25" (635 mm)
Master (outer) case height19" (482.6 mm)
Master (outer) case weight45 lbs (20.4 kg)
Quantity per master (outer) case8 pc(s)
Country of originUnited States
