Lantronix SecureLinx SLC32 - Terminal server - 32 ports - Ethernet Fast Ethernet RS-232 PPP - DC power - 1U

Lantronix

SALE PRICE
$3,530.49
REGULAR PRICE $3,640.00
Product Overview:

Lantronix SecureLinx SLC32 - Terminal server - 32 ports - Ethernet, Fast Ethernet, RS-232, PPP - DC power - 1U

MFG#:SLC03224N-03
Product Category:Serial Console Servers
★★★★☆4.1/5
Rate Us on Trustpilot

Additional information

Product Description:

Lantronix SecureLinx SLC32 - Terminal server - 32 ports - Ethernet, Fast Ethernet, RS-232, PPP - DC power - 1U
The SecureLinx SLC32 secure console servers provide secure, remote access to servers and IT infrastructure equipment, whether it's located down the hall or across the globe. IT professionals can use SecureLinx SLC to monitor, manage and troubleshoot nearly anything in the data center rack, from anywhere, at any time - even if servers or networks are down. This capability means faster response rates, which translate into reduced costs and less downtime.

With a common GUI interface that is simple to set up and use, SecureLinx SLC serial console server provides easy, secure administration and management of IT equipment - from anywhere, at any time.



Main Specifications

Product Description Lantronix SecureLinx SLC32 - terminal server
Device Type Terminal server
Enclosure Type External - 1U
Dimensions (WxDxH) 17.2 in x 12 in x 1.7 in
Weight 9.9 lbs
Ports Qty 32
Data Link Protocol Ethernet, Fast Ethernet, RS-232, PPP
Network / Transport Protocol TCP/IP, UDP/IP
Remote Management Protocol SNMP 1, SNMP 2, SNMP, Telnet, SNMP 3, HTTP, SSH
Capacity Concurrent sessions : 64
Features Firewall protection, dynamic IP address assignment , DHCP support, BOOTP support, LDAP support, packet filtering, dynamic DNS server, manageable, E-mail alert
Power DC -24/-60 V
Manufacturer Warranty 2 years warranty


Extended Specifications

General
Device Type Terminal server
Height (Rack Units) 1U
Built-in Devices Status LCD, keypad
Width 17.2 in
Depth 12 in
Height 1.7 in
Weight 9.9 lbs
Processor / Memory / Storage
Hard Drive None.
Networking
Form Factor External
Ports Qty 32
Connectivity Technology Wired
Data Transfer Rate 100 Mbps
Data Link Protocol Ethernet, Fast Ethernet, RS-232, PPP
Network / Transport Protocol TCP/IP, UDP/IP
Routing Protocol RIP, RIP-2
Remote Management Protocol SNMP 1, SNMP 2, SNMP, Telnet, SNMP 3, HTTP, SSH
Capacity Concurrent sessions : 64
Features Firewall protection, dynamic IP address assignment , DHCP support, BOOTP support, LDAP support, packet filtering, dynamic DNS server, manageable, E-mail alert
Encryption Algorithm AES, SSL
Authentication Method Kerberos, Secure Shell (SSH), RADIUS, PAP, CHAP, TACACS+, Secure Shell v.2 (SSH2), LDAP
Expansion / Connectivity
Expansion Slot(s) 2 (total) / 2 (free) x CardBus
Interfaces 2 x network - Ethernet 10Base-T/100Base-TX - RJ-45
32 x serial - RS-232 - RJ-45
1 x management - console - RJ-45
Miscellaneous
Compliant Standards FCC Class A certified, UL, TUV, VCCI, C-Tick, CISPR 24, cUL, EN55022, GS, EN55024, EN55022 Class A, UL 60950, CISPR 22, CB, EN50204, RoHS
Power
Power Device Power supply - internal
Installed Qty 2
Max Supported Qty 2
Voltage Required DC -24/-60 V
Power Consumption Operational 20 Watt
Software / System Requirements
OS Provided Linux
Manufacturer Warranty
Service & Support 2 years warranty
Service & Support Details Limited warranty - 2 years
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 122 °F
Humidity Range Operating 30 - 90%
