Server Technology C4G36RA-2QBE2FE2 PRO4X PDU 208 Volt 36 Outlets 0U

Server Technology

MSRP: $4,491.00 SALE PRICE
$3,817.35

REGULAR PRICE $4,086.81

(You Save $673.65)

MFG#:C4G36RA-2QBE2FE2
Product Category:PDU
Platform:PRO4X
Metering and Switching:Switched POPS
★★★★4.1/5
Rate Us on Trustpilot

Additional information

Description:

Server Technology's PRO4X Switched POPS PDUs run on our state-of-the-art Xerus network interface platform and provide remote access to power, PDU status, input, outlet and branch current monitoring, and outlet on/off control. The PDU features RamLock, a self-locking mechanism to prevent accidental cord disconnects, and our award-winning HDOT Cx outlets that can be deployed as either a C13 or C19. Switched POPS PDUs are secured with strong configurable password, active directory, 256-bit AES encryption, SSH, SSL and HTTPS support. SNMP traps provide automated alerts on power and environmental conditions from Legrand's plug-and-play environmental monitoring sensors like temperature, humidity, water, dry contact closure, airflow, air pressure differential, and more.

  • HDOT CX OUTLETS: Cx is the future-ready UL tested hybrid of a C13 and C19 outlet accommodating both C14 and C20 plugs.
  • 45 DEGREE ANGLED INFEED: The angled infeed improves accessibility, provides infeed strain relief, and its bend radius is suitable with 60A rated cords.
  • NETWORK MONITORING: Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more.
  • MULTI-UNIT LINKING & CASCADING: Daisy chain up to 16 PDUs from a primary PDU using a USB or Ethernet connection through a single IP address.
  • MULTI-COLOR LCD: An easy-to-read LCD provides a local indication of power usage, alerts, and alarms.
  • HOT SWAPPABLE CONTROLLER: The Controller is the PDU's center of intelligence and houses computing, display, and connectivity ports.
  • POWER QUALITY MEASUREMENTS: Monitor and alert on the power being fed to the PDU for harmonics, voltage dips and swells, crest factor, and more at the outlet or load.
  • RGB LED OUTLET INDICATORS: RGB LEDs identify an outlet's on/off state, if it's above/below a certain power threshold, or if it's in suspect of a power measurement irregularity.
  • WAVEFORM CAPTURE: Capture voltage and current waveforms automatically or upon demand.
  • ENVIRONMENTAL MONITORING: Support up to 12 daisy chained DX2-series SmartSensors, each with the ability to send SNMP-based alerts and email notifications.
  • PER-INLET POWER SENSING: PIPS® (Per Inlet Power Sensing) Monitors Current Load (A), Voltage (V), Power (W), Apparent Power (VA), Crest Factor, Power Factor, & Energy per inlet.
  • PER-OUTLET POWER SENSING: POPS® (Per Outlet Power Sensing) Monitors Current Load (A), Voltage (V), Power (W), Apparent Power (VA), Crest Factor, Power Factor, and Energy per outlet.
  • BRANCH CIRCUIT PROTECTION: This PDU meets the UL and IEC 62368-1 requirement for branch circuit protection through UL 489 rated magnetic-hydraulic circuit breakers or UL 248 fuses.
  • OUTLET CONTROL: On Switched PDUs, cycle power to individual outlets or groups of outlets to reboot servers, or power off unused receptacles.

Specifications:

Interfaces/Ports
Network (RJ-45)Yes
Management
Management
  • HTTP/HTTPS
  • TLSv1.2S
  • SHv2
  • Telnet
  • SNMPv2c
  • v3 (GET, SET, Traps)
  • IPv4
  • IPv6
  • LDAPv3/LDAPS
  • TACACS+
  • RADIUS
  • FTP/SFTP
Remote Outlet SwitchingYes
Physical Characteristics
Height70"
Width2.2"
Depth2.5"
Power Description
Circuit BreakerYes
Input Current60 A
Power Rating (Watt)10 kW
General Information
Product TypePDU
Manufacturer Part NumberC4G36RA2QBE2FE2
Manufacturer Website Addresshttp://www.servertech.com
ManufacturerServer Technology, Inc
Product NamePRO4X 36-Outlets PDU
Product SeriesPRO4X
Brand NameServer Technology
Technical Information
FeaturesLCD Display
Multi-color LCD
Protection TypeCircuit Protection
Circuit Breaker
Branch Circuit
Fuse
Plug/Connector TypeIEC 208V/60A 2P+G 6Hr
Receptacle TypeIEC 60320 C13
CX
Environmental SensorsTemperature
Differential Pressure
Humidity
Water
Air Flow
Contact Closure
Locking ReceptaclesRamLock Locking Outlet
Receptacle Detail12 x IEC 60320 C13
24 x CX
