Server Technology C-12H1B211E7 PDU 120 Volt 12 Outlets 1U

Server Technology

SALE PRICE
$332.00
REGULAR PRICE $390.00
MFG#:C-12H1B211E7
Product Category:PDU
Metering and Switching:Metered
Total Outlets:12
★★★★☆4.1/5
Rate Us on Trustpilot

Additional information

Description:

The Server Technology® Metered PDU provides reliable power distribution with local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet.

Inputs

Input Voltage (V):120
Input Plug:NEMA L5-30P
Input Current (A):30
Input Current Rated (A):24
Input Power Capacity (kW):2.8

Outputs

ConnectorRating
(12) x IEC 60320/C13North American Rating: ≤ 12A @208V L-N (15A Peak)

Branch Circuit Protection

(2) 20A Fuses, two (2) branch, meets UL 60950-1 requirements (Bussmann SC-20 fuses), 100 kA Interrupt Rating

Physical

Dimensions: 1.75in tall x 17.2in wide x 5.0in deep [45mm x 437mm x 127mm]

Environmental

Operating Environment: 32°F to 140°F / 0°C to 60°C | 8%RH to 90%RH non-condensing | 6,500ft/2km elevation
Storage Environment: -40°F to 185°F / -40°C to 85°C | 8%RH to 90%RH non-condensing | 50,000ft/15km elevation
Quiescent / Unloaded Power Draw: < 10W for all configurations

Communications & Security

Not Applicable

Certifications

North American:
Safety (Listed & Certified, cTUVus mark)
  • UL 62368-1
  • CSA C22.2 No. 62368-1

Measurement Accuracy

Input Measurement Accuracy:
LED Current = ± 10% at 0.1 amp (1.0 - 9.9 amps) and 1 amp (> 9.9 amps) resolution
