Raritan PX4-5161-E7 3PH 208V 50A (derated to 40A) 36 Outlets PDU

Raritan

MSRP: $2,463.00
Regular Price $2,094.00
Discount Price: $2,020.00
(You save $443.00 )
Shipping:
Free Shipping
Product Overview:

3PH, 208V, 50A (derated to 40A), 36 Outlets: 18 x Locking C13, 18 x Locking Cx, Input: CS8365C 50A, 0U, 14.4kVA, 6 x 10kAIC breakers

MFG#:
PX4-5161-E7
Product Category:
PDU
Adding to cart… The item has been added

Description

3PH, 208V, 50A (derated to 40A), 36 Outlets: 18 x Locking C13, 18 x Locking Cx, Input: CS8365C 50A, 0U, 14.4kVA, 6 x 10kAIC breakers, Outlet Metered and Switched, iX controller with 2 x 10/100/1000 ETH port, 2 x USB-A, 1 x USB-B, RJ-45 Sensor and PDU Link port

Specifications:

Features

    Energy Metering

    Voltage (V), Current (A), Active Power (kW), Real Power (kVA), Energy (kWh), Power Factor

    Metering Accuracy

    ISO/IEC 62053-21 1%

    Remote Outlet Switching

    Yes

    Metering per input line

    Yes

    Metering per Branch Circuit Breaker

    Yes

    Environmental Sensor Ready

    Yes

    Compatible Sensors

    Temperature, Humidity, Air Flow, Differential Pressure, Water Leak, and Contact Closure.

    Cascading

    Yes, Max 16 PDUs can be daisy chained using a USB or Ethernet connection.

    Networking

    (10/100/1000 Base T) Ethernet, Secondary redundant (10/100 Base T) Ethernet. Optional WiFi (802.11 a/b/g/n).

    Onboard Display

    Color, matrix LCD display : Voltage, current, or active power (per line, per breaker, or per receptacle / outlet); Alarms; Configuration information (name, ratings, IP / Networking information). Auto-flip orientation

    Specifications

    Input

    Input Plug

    IEC 230V/32A 2P+PE 6Hr

    Nominal Voltage

    230V

    Maximum Input Current

    32A

    Rated Input Current

    32A

    Power Capacity

    7.4kVA

    Cord Length

    3m


    Output

    Nominal Voltage

    nullV

    Receptacles (Output Connections)

    (12) C13, (12) Cx

    Overload Protection

    2


    Physical

    Dimensions (WxDxH)

    56mm x 65mm x 1539mm

    Unit Weight

    11kg

    Shipping Weight

    nullkg

    Shipping Dimensions

    Mounting




    Environmental

    Operating Temperature/Environment

    60 C

    Operating Relative Humidity

    85%

    Operating Elevation

    0-6000ft



    Conformance

    Regulatory Approvals

    Warranty

    Standard 2 years manufacturer warranty
