Raritan PX3-5497V-C5 24-Outlet PDU

Raritan

SALE PRICE
$1,506.00

REGULAR PRICE $1,836.00
MFG#:PX3-5497V-C5K1
Product Category:PDU
Model or Line:PX3
Availability:Call for Availability
★★★★4.1/5
Rate Us on Trustpilot

Additional information

Description:

Raritan PX3-5497V-C5 24-Outlet PDU - NEMA L6-30P - 20 x IEC 60320 C13, 4 x IEC 60320 C19 - 230 V AC - 5000 W - 0U - Rack-mountable

The PX series boasts the most reliable and sophisticated rack PDUs on the market. It offers metering at the inlet, outlet, and PDU circuit breaker level. And tracks current, voltage, power, power factor, and energy usage within 1% billing-grade accuracy. In short, it helps you to better manage existing power capacity, and save energy.

But the PX series offers more than reliable power distribution and metering. It also supports sensors that ensure your equipment is operating in a safe environment. And remote outlet switching to ensure proper provisioning and avoid tripped circuit breakers. Or reboot hung servers. All without stepping foot in the data center.

We offer hundreds of models that meet all your needs. Whether you have a small, medium, or large data center; densely packed 400V three-phase racks; high power blade servers; or a lights-out colo deployment -- there's a PX just for you. See more reasons to consider the PX below.

Features
  • PDU provides power control as remote controlled relay & load monitoring
  • NEMA L6-30P plug/connector type for better, dependable connectivity and desired power output
  • IEC 60320 C13 receptacle type to ensure maximum productivity with added feasibility
  • 230 V AC input voltage for better reliance and maximum dependability
  • 208 V AC output voltage for maximum dependability and added productivity

Specifications:

Miscellaneous
Environmentally Friendly Yes
Physical Characteristics
Weight (Approximate) 11.46 lb
Mount Type Rack-mountable
Rack Height 0U
Height 60.6"
Width 2.1"
Depth 2.6"
Power Description
Input Voltage 230 V AC
  230 V AC
Output Voltage 208 V AC
  208 V AC
Input Current 24 A
Power Rating (VA) 5000 VA
Technical Information
Protection Type Overload Protection
Plug/Connector Type NEMA L6-30P
Receptacle Type IEC 60320 C19
  IEC 60320 C13
Receptacle Detail 20 x IEC 60320 C13
  4 x IEC 60320 C19
General Information
Product Type PDU
Manufacturer Part Number PX3-5497V-C5K1
Manufacturer Website Address http://www.legrand.us
Manufacturer Legrand Group
Product Model PX3-5497V-C5
Product Name PX3-5497V-C5 24-Outlet PDU
Product Series PX
Brand Name Raritan
