Description:
Raritan PX3-5475V-K1 24-Outlet PDU - NEMA L5-20P - 24 x NEMA 5-20R - 120 V AC - 1900 W - 0U - Rack-mountable
The Raritan PX family of high-quality, intelligent rack power distribution units (iPDUs) offers real-time remote power monitoring of current (amps), voltage, power (kVA, kW) and energy consumption (kWh) with +/- 1% billing-grade accuracy, even at individual outlets. The PX series offers hundreds of models to meet all your data center applications, including models with remote outlet switching, individual outlet metering, high-power for blade servers and high-density applications, and 400V power distribution.
Features - PDU provides active metering enabling energy optimization and circuit protection
- NEMA L5-20P plug/connector type for efficient connectivity and feasible power output
- NEMA 5-20R receptacle type to ensure maximum productivity with added feasibility
- 120 V AC input voltage for maximum feasibility and added productivity
Specifications:
| Miscellaneous | | Country of Origin | Taiwan | | Physical Characteristics | | Mount Type | Rack-mountable | | Rack Height | 0U | | Technical Information | | Plug/Connector Type | NEMA L5-20P | | Receptacle Type | NEMA 5-20R | | Receptacle Detail | 24 x NEMA 5-20R | | Power Description | | Input Voltage | 120 V AC | | | 120 V AC | | Input Current | 16 A | | Power Rating (VA) | 1900 VA | | | General Information | | Product Type | PDU | | Manufacturer Part Number | PX3-5475V-K1 | | Manufacturer Website Address | http://www.legrand.us | | Manufacturer | Legrand Group | | Product Model | PX3-5475V-K1 | | Product Name | PX3-5475V-K1 24-Outlet PDU | | Product Series | PX | | Brand Name | Raritan | |
