| 1PH, 208V AC, 30A (24A rated); 4 outlets: 4x C19; plug: NEMA L6-30P (Rear feed), 5.0kVA; Outlet Metered/Switched, 1U horizontal PDU, SecureLock ready, high resolution color display, Ethernet, serial, 2x USB-A, USB-B and sensor connections Specifications: FEATURES
Energy Metering Voltage (V), Current (A), Active Power (kW), Real Power (kVA),
Energy (kWh), Power Factor
Metering Accuracy ISO/IEC 62053-21 1% (see page 3 for details)
Metering per Input Line Yes
Metering per Branch Circuit Breaker Yes
Metering per Output Receptacle Yes
Remote Outlet Switching Yes
Environmental Sensor Ready Yes
Replaceable Controller No
Compatible Sensors Temperature, Humidity, Air Flow, Differential Pressure, Water
Leak, and Contact Closure
Networking Gigabit (10/100/1000 BaseT) Ethernet port; secondary, redundant
(10/100 BaseT) Ethernet port. Optional WiFi (802.11a/b/g/n)
Remote Management HTTP(s); SSH; Telnet; RS-232 (Serial); Power IQ; SNMP version
v2/v3; SMTP; JSON-RPC; Modbus over TCP
Cascading Yes, Max 16 PDUs can be daisy chained using a USB connection
and 32 PDUs using Ethernet connection
Onboard Display
Color, matrix LCD display : Voltage, current, or active power (per
line, per breaker, or per receptacle / outlet); Alarms; Configuration
information (name, ratings, IP / Networking information)
Embedded Processor ARM Cortex A5 536MHZ (Atmel A5D35A), 16MB SPI Flash, 64MB DDR2 RAM
1
Technical Specifications / Engineering Submittals
Raritan Model Number: PX3-5092R-F8 rev20240510
INPUT
Input Plug IEC 60309 2P+E 6h 32A (2P3W)
Cord Length 3 meters (9.84 feet) standard
Cord Entry Rear feed
Cable Type IP44("splashproof")
Number of Power Cords 1
Maximum Input Current 32A
Nominal Input Voltage 230V
Rated Input Voltage 200 - 240V
Input Frequency 50/60Hz
Power Capacity 6.4kVA at 200V, 7.7kVA at 240V
OUTPUT
Nominal Output Voltage 230V
Rated Output Voltage 200 - 240V
Receptacles (Output Connections) (4) IEC320 C19, 16A
Securelock Support Yes
Cord Retention No
Overload Protection (4) Airpax LEGBX6-37483-16-V
PHYSICAL
Color Black powder coat (custom colors available)
Unit Dimensions (WxDxH) 17.3" x 7.2" x 1.7" ; 440mm x 183mm x 44mm
Unit Weight 6.6 kg
Shipping Weight 7.2 kg
Shipping Dimensions (WxDxH) 22.44" x 16.34" x 12.6" ; 570mm x 415mm x 320mm
Mounting RACK-KIT-DPX-1U
2
Technical Specifications / Engineering Submittals
Raritan Model Number: PX3-5092R-F8 rev20240510
ENVIRONMENTAL
Operating Temperature 60°C
Operating Relative Humidity 85%
Operating Elevation 0-10000ft
CONFORMANCE
Regulatory Approvals CE, Canada ICES-003, Part 15 Class A of the FCC rules,
RoHS compliant
Warranty Standard 2 years manufacturer warranty |
