Raritan PX3-3186 3PH 208-240V AC 100A Zero U PDU
Raritan
MSRP: $4,259.00 SALE PRICE$3,705.33
REGULAR PRICE $3,833.10
(You Save $553.67)
3PH, 208-240V AC, 100A (80A/PH rated), 1 line, input type: 1x IEC 60309 3P+E 9h 100A (Delta), output type: 1x IEC 60309 3P+E 9h 100A, Zero U, high resolution color display
Additional information
Features
Voltage (V), Current (A), Active Power (kW), Real Power (kVA), Energy (kWh), Power Factor
Metering Accuracy
ISO/IEC 62053-21 1%
Remote Outlet Switching
No
Metering per input line
Yes for all models
Metering per Branch Circuit Breaker
No
Environmental Sensor Ready
Yes
Compatible Sensors
Temperature, Humidity, Air Flow, Differential Pressure, Water Leak, and Contact Closure.
Cascading
Yes, Max 16 PDUs can be daisy chained using a USB or Ethernet connection.
Networking
(10/100/1000 Base T) Ethernet, Secondary redundant (10/100/1000 Base T) Ethernet. Optional WiFi (802.11 a/b/g/n).
Onboard Display
Color, matrix LCD display : Voltage, current, or active power (per line); Alarms; Configuration information (name, ratings, IP / Networking information).
Specifications
Input
Input Plug
IEC 60309 3P+E 9h 100A (3P4W)
Nominal Voltage
208V
Maximum Input Current
100A
Rated Input Current
80A
Power Capacity
0kVA
Cord Length
3m
Output
Nominal Voltage
208V
Receptacles (Output Connections)
(1) IEC309 3P+E 9h 100A
Overload Protection
NA
Physical
Dimensions (WxDxH)
4.2in x 4.5in x 17.1in; 107mm x 114mm x 435mm
Unit Weight
11.5 LBS
Shipping Weight
13 LBS
Shipping Dimensions
320mm x 180mm x 1135mm
Mounting
Tool-less Button Mount
Environmental
Operating Temperature/Environment
60 C
Operating Relative Humidity
85%
Operating Elevation
0-6000ft
Conformance
Regulatory Approvals
UL
Warranty
Standard 2 years manufacturer warranty
