Product Description:
The KH1508i KVM Switche is control unit that allow access to multiple computers from a single KVM console. It uses TCP/IP for its communications protocol, it can be accessed from any computer on the Net - whether that computer is located down the hall, down the street, or half-way around the world.
Package Contents:
- 1x Cat 5 High-Density KVM Over the NET™
- 1x Power Cord
- 1x Firmware Upgrade Cable
- 1x Rack Mount Kit
- 1x Foot Pad Set(4 pcs.)
- 1x User Manual
- 1x Quick Start Guide
Features:
- 8-port remote access KVM switch - monitor and control up to 8 computers from a single KVM (Keyboard, Video, Mouse) console.
- Remotely access computers via LAN, WAN, or the Internet; control your installation when and where you want.
- Extends the distance between computers and switch - up to 30m for resolutions of 1600 x 1200 @ 60Hz; up to 40m for resolutions of 1280 x 1024 @ 75Hz.
- Internet browser access; Windows client and Java client provided; Java client works with most operating systems.
- No software required - convenient computer selection via port selection switches, hotkeys and intuitive On Screen Display (OSD) menus.
- Supports all major server platforms and VT100 based serial devices.
- Supports multiplatform server environments including PS/2, USB, Sun,and Serial.
- RJ-45 connectors allow a full 8 port implementation - Cat 5e/6 cable reduces cable bulk.
- Dedicated chain ports - daisy chain up to 15 additional units - control up to 128 computers from a single console.
- Extends the distance between computers and switch - up to 40m.
- Up to 64 user accounts - up to 32 concurrent logins.
- Panel Array Mode - view all 8-ports at the same time.
- Message board feature allows logged in users to communicate with each other and allows a user to take exclusive control of the KVM functions.
- Windows-based Log Server.
- Remote power control for attached Power Over the NET™ devices.
- Advanced security features include password protection and advanced encryption technologies - 1024-bit RSA, 256-bit AES, 56-bit DES, and 128-bit SSL.
- RADIUS server support.
- Firmware upgradeable.
- Network Interfaces: TCP/IP, HTTP, HTTPS, UDP, RADIUS, DHCP, SSL, ARP, DNS, 10Base- T/100Base-TX, auto sense, Ping.
- High video resolution: up to 1600 x 1200 @ 60Hz
- Multiplatform support: Windows 2000/XP/Vista,Linux, Mac, Unix, SUN and FreeBSD.
Specifications:
| Computer Connections |
Direct | 8 | |
| Max. | 128 (via Daisy Chain) | ||
| Port Selection | OSD;Hotkey;Pushbutton | ||
| Connectors | Console Ports | Keyboard | 1 x Mini Din 6 Female (Purple) |
| Video | 1 x HDB-15 Female (Blue) | ||
| Mouse | 1 x Mini Din 6 Female (Green) | ||
| KVM Ports | 8 x RJ-45 Female | ||
| Daisy Chain Ports | 1 x DB-25 Male (Black) | ||
| Power | 1 x 3 Prong AC Socket | ||
| LAN | 1 x RJ-45 Female | ||
| PON | 1 x DB-9 Male (Black) | ||
| Switches | Reset | 1 x Semi-recessed Pushbutton | |
| Power | 1 x Rocker | ||
| Power Selection | 8 x Pushbutton | ||
| F/W Upgrade | 1 x Slide | ||
| LEDs | On Line | 8 (Green) | |
| Selected | 8 (Orange) | ||
| Power | 1 (Blue) | ||
| Station ID | 2 x 7 segment (Orange) | ||
| Link | 1 (Green) | ||
| 10/100Mbps | 1 (Orange/Green) | ||
| Emulation | Keyboard/Mouse | PS/2; USB (PC/Mac/Sun); Serial | |
| Video | Local | 1600 x 1200@60Hz (30m); 1280 x 1024@75Hz (40m) |
|
| Remote | 1280 x 1024@75Hz | ||
| Scan Interval | 1~255 Seconds | ||
| I/P Rating | 100-240 V AC; 50/60Hz | ||
| Power Consumption | 120V/12W; 230V/12W | ||
| Environment | Operating Temp. | 0-50˚C | |
| Storage Temp. | -20-60˚C | ||
| Humidity | 0-80% RH, Non-condensing | ||
| Physical Properties | Housing | Metal | |
| Weight | 2.80 kg | ||
| Dimensions ( L x W x H ) |
43.70 x 16.10 x 4.40 cm (19"/1U) | ||
