Black Box ACR101A-DVI ServSwitch Wizard IP Single-Server IP Gateway

Black Box

Regular Price $1,071.00
Discount Price: $985.00
Product Overview:

ServSwitch Wizard IP DXS, Single-Server IP Gateway, DVI - 1 Computer(s) - 4 Remote User(s)

Adding to cart… The item has been added


Black Box ServSwitch Wizard IP DXS, Single-Server IP Gateway, DVI - 1 Computer(s) - 4 Remote User(s) - WUXGA - 1920 x 1200 Maximum Video Resolution - 1 x Network (RJ-45) - 2 x USB - 1 x DVI - Rack-mountable OVER IP SINGLE-SVR IP


ServSwitch Wizard IP DXS, Single-Server IP Gateway, DVI

Quick Facts

  • Easily log into and control a computer via the Internet or a corporate network.
  • Enables direct KVM-over-IP (KVMoIP) computer management.
  • Works with CPUs and servers with DVI-D video output.
  • Supports virtual media (VM).

Further Details

  • Network-independent operation. Provides full control during bootup.
  • Enables BIOS-level control of a computer during crash states.
  • Supports virtual media via USB for easy remote file transfer.
  • Highly secure and supports both IPV4 and IPV6 addresses.
  • Includes Windows® VNC viewer for configuring settings and making connections.
  • Ideal for remotely upgrading or patching distant host systems.
  • Enables same-session access by up to four remote users at one time.
  • Compact, palm-sized unit can be rackmounted in the ACU5000A.

Set up remote, secure access to a computer with digital DVI-D video output using the ServSwitch™ Wizard IP DXS, Single-Server IP Gateway, DVI, a multiuser, point-to-point KVM-over-IP solution. With it, you get full control of a connected CPU or server down to the BIOS level.

Communicating over a standard IP network, the IP gateway provides system administrators with full non-blocking remote access from anywhere in the world. Its small size and included Windows® VNC viewer application make this KVM-over-IP solution ideal for enterprise remote management.


Specifications are provided by the manufacturer. Refer to the manufacturer for additional explanations. Product may not be exactly as shown.

Limited Warranty 2 Year
Maximum Video Resolution 1920 x 1200
Graphic Mode WUXGA
Power Description
Input Voltage 110 V AC
220 V AC
Power Consumption 12.50 W
Technical Information
Connectivity Technology Wired
KVM Technology Digital
Number of Computers Supported 1
Number of Remote Users Supported 4
General Information
Product Type KVM Extender
Manufacturer Part Number ACR101A-DVI
Manufacturer Website Address
Manufacturer Black Box Corporation
Product Name ServSwitch Wizard IP DXS, Single-Server IP Gateway, DVI
Product Line ServSwitch
Brand Name Black Box
Package Contents
  • ServSwitch Wizard IP DXS, Single-Server IP Gateway, DVI
  • 5-VDC Power Supply with 6-ft. (1.8-m) Cord
  • Set of (4) Rubber Feet
  • Rackmounting Bracket with (3) screws (to be Used with the ACU5000A, Sold Separately)
  • USB Type A to B Cable
  • 3.5-mm Audio Cable, 10 ft. (3 m)
  • DVI-D Cable, 6 ft. (1.8 m)
  • End User License Agreement for VNC Application
  • Safety Guide
Platform Supported PC
Certifications & Standards CE
Environmentally Friendly Yes
Environmental Certification RoHS
Physical Characteristics
Form Factor Rack-mountable
Transmitter Height 1.10"
Transmitter Width 4.90"
Transmitter Depth 3"
Transmitter Weight (Approximate) 11.20 oz
Headphone Yes
Number of Network (RJ-45) Ports 1
Network (RJ-45) Yes
Number of USB Ports 2
Number of DVI Ports 1
