Description:
The VE601 DVI HDBaseT-Lite Extender is able to extend a DVI 1080p display up to 70 m using an Ethernet cable. This combination of ATEN and HDBaseT technology even supports sharing 1920 x 1200 media up to 40 m away, offering a simple, adaptable, and cost-effective solution for any professional A/V installation.
The VE601 DVI HDBaseT-Lite Extender is the perfect solution for professional A/V installations that require video signal interference protection, such as in medical and military installations. With its lightweight and easy-to-mount design, not to mention slip-resistant DC Jack lock mechanism, the VE601 can be installed nearly anywhere while ensuring peace of mind with its unerring reliability
Specifications:
| Product Type: |
Video Extender Transmitter |
| Connectivity Technology: |
Wired |
| Brand Name: |
ATEN |
| Maximum Operating Distance: |
229.66 ft |
| Number of Network (RJ-45) Ports: |
1 |
| Media Type Supported: |
Twisted Pair |
| Number of Input Devices Supported: |
1 |
| Number of DVI Inputs: |
1 |
| General Information |
|---|
| Product Type: |
Video Extender Transmitter |
| Manufacturer Part Number: |
VE601T |
| Manufacturer Website Address: |
http://www.aten.com/us/en/ |
| Manufacturer: |
ATEN Technology Inc |
| Product Model: |
VE601T |
| Product Name: |
VE601T Video Extender |
| Brand Name: |
ATEN |
| Interfaces/Ports |
|---|
| Number of Network (RJ-45) Ports: |
1 |
| Network (RJ-45): |
Yes |
| DVI In: |
Yes |
| Number of DVI Inputs: |
1 |
| Media & Performance |
|---|
| Twisted Pair Cable Standard: |
Category 6a |
| Media Type Supported: |
Twisted Pair |
| Miscellaneous |
|---|
| Package Contents: |
|
| Environmentally Friendly: |
Yes |
| Environmental Certification: |
RoHS |
|
WEEE |
| Physical Characteristics |
|---|
| Transmitter Height: |
1.20" |
| Transmitter Width: |
3.40" |
| Transmitter Depth: |
4.10" |
| Transmitter Weight (Approximate): |
9.60 oz |
| Technical Information |
|---|
| Connectivity Technology: |
Wired |
| Maximum Operating Distance: |
229.66 ft |
| Number of Input Devices Supported: |
1 |
| Video |
|---|
| Graphics Modes: |
WUXGA |
| Maximum Video Resolution: |
1920 x 1200 |
