Description:
The VE601 DVI HDBaseT-Lite Extender is able to extend a DVI 1080p display up to 70 m using an Ethernet cable. This combination of ATEN and HDBaseT technology even supports sharing 1920 x 1200 media up to 40 m away, offering a simple, adaptable, and cost-effective solution for any professional A/V installation.
The VE601 DVI HDBaseT-Lite Extender is the perfect solution for professional A/V installations that require video signal interference protection, such as in medical and military installations. With its lightweight and easy-to-mount design, not to mention slip-resistant DC Jack lock mechanism, the VE601 can be installed nearly anywhere while ensuring peace of mind with its unerring reliability.
Media & Performance
| Twisted Pair Cable Standard | Category 6a |
| Media Type Supported | Twisted Pair |
Video
| Graphics Modes | WUXGA |
| Maximum Video Resolution | 1920 x 1200 |
Miscellaneous
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
| WEEE |
General Information
| Product Type | Video Extender Transmitter/Receiver |
| Manufacturer Part Number | VE601 |
| Manufacturer Website Address | http://www.aten.com/us/en/ |
| Manufacturer | ATEN Technology Inc |
| Product Model | VE601 |
| Product Name | VE601 DVI HDBaseT-Lite Extender (HDBaseT Class B) |
| Brand Name | ATEN |
Physical Characteristics
| Transmitter Height | 1.20" |
| Transmitter Width | 3.40" |
| Transmitter Depth | 4.10" |
| Transmitter Weight (Approximate) | 1.20 lb |
Technical Information
| Connectivity Technology | Wired |
| Maximum Operating Distance | 229.66 ft |
| Number of Output Devices Supported | 1 |
| Number of Input Devices Supported | 1 |
Interfaces/Ports
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Number of DVI Outputs | 1 |
| DVI In | Yes |
| DVI Out | Yes |
| Number of DVI Inputs | 1 |
