ATEN KX9970FT 5K DisplayPort KVM over IP Transmitter - 1 Computer(s) - 2 Local User(s) - 32808.40 ft Range - 5K - 5120 x 2880 Maximum Video Resolution - 3 x USB - DisplayPort - 12 V DC Input Voltage - Rack-mountable - For PC
As workplaces face restructuring and decentralization is inevitably enforced, control room operations are being challenged to pivot effectively throughout these safety protocols in the new normal. Despite manpower shortages, managing escalations with secure, precise, and timely data from real-time monitoring and dynamic collaboration has become measurably more mission-critical than ever.
The KX9970FT is a high-performance KVM over IP transmitter that allows connection to a DisplayPort computer and enables secure, remote, and uninterrupted access to the computer from a 5K DisplayPort KVM console connected to a KX9970FR receiver over an Intranet or a dedicated LAN. With the receiver console installed at a separate location from the transmitter within a standard IP network, mission-critical control room operations become more ergonomic, user-centered, and task-oriented, while remaining separate from any adverse environmental interference.
Specifications:
| Warranty |
| Limited Warranty |
3 Year |
| Miscellaneous |
| Package Contents |
- KX9970FT 5K DisplayPort KVM over IP Transmitter
- 1 x DisplayPort Cable
- 1 x USB Type-A to Type-B Cable
- 1 x Mounting Kit
- 1 x Power Adapter
- 1 x Foot Pad Set (4 pcs)
- 1 x User Instructions
|
| Platform Supported |
PC |
| Power Description |
| Input Voltage |
12 V DC |
| Power Consumption |
17.99 W |
| Video |
| Maximum Video Resolution |
5120 x 2880 |
| Graphic Mode |
5K |
| Interfaces/Ports |
| USB |
Yes |
| Number of USB Ports |
3 |
| DisplayPort |
Yes |
|
| Physical Characteristics |
| Form Factor |
Rack-mountable |
| Transmitter Height |
1.65" |
| Transmitter Width |
6.42" |
| Transmitter Weight (Approximate) |
2.43 lb |
| Transmitter Length |
8.46" |
| Technical Information |
| Connectivity Technology |
Wired |
| Maximum Operating Distance |
32808.40 ft |
| Number of Computers Supported |
1 |
| Number of Local Users Supported |
2 |
| Device Type |
KVM Extender |
| General Information |
| Product Type |
KVM Extender Transmitter |
| Manufacturer Part Number |
KX9970FT |
| Manufacturer Website Address |
http://www.aten.com/us/en/ |
| Packaged Quantity |
1 |
| Manufacturer |
ATEN Technology, Inc |
| Product Model |
KX9970FT |
| Product Name |
KX9970FT 5K DisplayPort KVM over IP Transmitter |
| Brand Name |
ATEN |
|
