Description:
The VE882 is an Optical HDMI Extender that overcomes the length restriction of standard HDMI cables by using optical fiber to send high definition audio and video signals over large distances.
The VE882 accepts an audio-video stream from a local source and serializes the data to pass it over a single 3.125 Gbps optical link (for resolutions up to 1080p@60Hz at 24-bits).
The VE882 can also extend the IR remote control and transfer RS-232 (up to 115kbps) in both directions, allows you to connect serial devices such as touch screens and barcode scanners
Specifications:
| Product Type: |
Video Extender Transmitter/Receiver |
| Connectivity Technology: |
Wired |
| Form Factor: |
Rack-mountable |
| Brand Name: |
ATEN |
| Maximum Operating Distance: |
1968.50 ft |
| Number of HDMI Inputs: |
1 |
| Media Type Supported: |
Optical Fiber |
| Number of Output Devices Supported: |
1 |
| Number of Input Devices Supported: |
1 |
| General Information |
|---|
| Product Type: |
Video Extender Transmitter/Receiver |
| Manufacturer Part Number: |
VE882 |
| Manufacturer Website Address: |
http://www.aten.com/us/en/ |
| Manufacturer: |
ATEN Technology Inc |
| Product Name: |
HDMI Optical Extender |
| Brand Name: |
ATEN |
| Interfaces/Ports |
|---|
| Number of HDMI Inputs: |
1 |
| Number of HDMI Outputs: |
1 |
| HDMI In: |
Yes |
| HDMI Out: |
Yes |
| Number of LC Ports: |
1 |
| Media & Performance |
|---|
| Media Type Supported: |
Optical Fiber |
| Miscellaneous |
|---|
| Package Contents: |
- HDMI Optical Extender
- 1 x IR Transmitter
- 1 x IR Receiver
- 1 x Mounting Kit
- 2 x Power Adapters
- 1 x User Instructions
|
| Environmentally Friendly: |
Yes |
| Environmental Certification: |
WEEE |
|
RoHS |
| Physical Characteristics |
|---|
| Material: |
Metal |
| Form Factor: |
Rack-mountable |
| Length: |
5.6" |
| Transmitter Height: |
1.23" |
| Transmitter Width: |
4.06" |
| Transmitter Weight (Approximate): |
14.82 oz |
| Power Description |
|---|
| Input Voltage: |
5.3 V DC |
| Technical Information |
|---|
| Connectivity Technology: |
Wired |
| Maximum Operating Distance: |
1968.50 ft |
| Number of Output Devices Supported: |
1 |
| Number of Input Devices Supported: |
1 |
| Video |
|---|
| Graphics Modes: |
Full HD |
| Maximum Video Resolution: |
1920 x 1080 |
