Description:
ATEN High Speed HDMI Cable with Ethernet provides an uncompressed, all-digital interface for both audio and video signals. Our cables infuse high-quality tinned copper wire to resist interference for improved image clarity. We offer HDMI cable at lengths of 2 to 20 meters with resolutions up to 4K DCI (4096 x 2160 @ 30Hz).
Features:
- Crystal-clear video up to 4K DCI (4096 x 2160 @ 30Hz), 4K UHD (3840 x 2160 @ 30Hz), and 1080p @ 60Hz signals
- HDMI Ethernet Channel functionality: additional dedicated data channel supports networking*
- HDMI (3D, Deep Color, 4K) and HDCP 2.2 compatible
- Gold-plated connectors for reliable transmissions
- Available in lengths from 2 to 20 m
- RoHS-compliant
* Feature only available if linked devices are HDMI Ethernet Channel enabled
Specifications:
| Video Resolution | Up to 4096X2160 @30Hz |
| Physical Properties | |
| Cable Length | 15m |
| Cable Color | Black |
| Cable Outer Dimension | 10.0+-0.2mm |
| Conductor Gauge | 24AWG |
| Conductor Material | Tinned Copper |
| Connector Plating | Gold |
| Connector Type | HDMI (19pin) Male to Male |
| Cable Shield Type | Aluminum Foil |
| Cable Jacket Type | PVC |
| Environmental | |
| Operating Temperature | 80℃ |
| Rating | UL VW-1 (Flame rate), CSA |
| Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
