Description:
The ATEN VM0404HA 4x4 4K HDMI Matrix Switch supports 4K resolutions of UHD (3840 x 2160) and DCI (4096 x 2160) with refresh rates of 30 Hz (4:4:4) and 60 Hz (4:2:0). Ready for the future of highdefinition video switching, the VM0404HA is ideal for applications where the routing of 4K digital signals is required, such as in classrooms, auditoriums, department stores and more.
The VM0404HA matrix switch offers an easy and affordable way to route any of 4 HDMI video sources to any of 4 HDMI displays and can be operated through front-panel pushbuttons, IR remote and RS-232 control, ensuring optimum viewing and control of high-definition video
Specifications:
| Basic |
|---|
| Product Type: |
HDMI Switcher |
| Device Supported: |
Control System |
|
Monitor |
| Color: |
Black |
| Brand Name: |
ATEN |
| General Information |
|---|
| Product Type: |
HDMI Switcher |
| Manufacturer Part Number: |
VM0404HA |
| Manufacturer Website Address: |
http://www.aten.com/us/en/ |
| Manufacturer: |
ATEN Technology Inc |
| Product Model: |
VM0404HA |
| Product Name: |
4x4 4K HDMI Matrix Switch VM0404HA |
| Brand Name: |
ATEN |
| Interfaces/Ports |
|---|
| Infrared: |
Yes |
| USB: |
Yes |
| Number of USB Ports: |
1 |
| Number of HDMI Inputs: |
4 |
| Number of HDMI Outputs: |
4 |
| Serial: |
Yes |
| HDMI In: |
Yes |
| HDMI Out: |
Yes |
| Number of Serial Ports: |
1 |
| Miscellaneous |
|---|
| Package Contents: |
- 4x4 4K HDMI Matrix Switch VM0404HA
- 1 x Power Adapter
- 1 x IR Remote Control
- 1 x IR Receiver
- 1 x Mounting Kit
- 1 x User Instructions
|
| Environmentally Friendly: |
Yes |
| Environmental Certification: |
RoHS |
|
WEEE |
| Physical Characteristics |
|---|
| Weight (Approximate): |
4.45 lb |
| Color: |
Black |
| Length: |
17.2" |
| Height: |
1.7" |
| Width: |
6.4" |
| Power Description |
|---|
| Input Voltage: |
5 V DC |
| Product Information |
|---|
| Device Supported: |
Control System |
|
Monitor |
