ATEN VB905 4K DisplayPort Booster
The ATEN VB905 is designed to extend True 4K signal from your source device to a display up to 5 meters, ensuring exceptional video quality and performance. With the ability to cascade up to 3 levels, you can achieve a total transmission distance of 20 meters without compromising on color and image quality.
Key Features:
- Extends True 4K signal transmission up to 5 meters
- Compliant with DisplayPort 1.2a and HDCP 2.2
- Superior video quality with resolutions up to 4096 x 2160 @ 60 Hz (4:4:4)
- Supports HDR for enhanced visual experience
- Cascade up to 3 levels for a total of 20 meters
- Plug-and-play installation for easy setup
- Rack mountable for flexible installation options
Note: For longer transmission distances, lower data rates may be possible. To maintain high-quality transmission, it is recommended to use higher quality cables.
Features
TypeAV repeater
Maximum resolution4096 x 2160 pixels
Maximum transfer distance787.4" (20 m)
LED indicatorsPower
HDCP✓
MaterialMetal
Rack mounting✓
Plug and Play✓
Product colorBlack
Ports & interfaces
Connectivity technologyWired
DisplayPorts in1
DisplayPorts out1
DC-in jack✓
Power
Operating voltage5 V
Current2.6 A
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Weight & dimensions
Width1.39" (35.3 mm)
Depth2.3" (58.4 mm)
Height0.811" (20.6 mm)
Weight1.76 oz (50 g)
Packaging content
AC adapter included✓
Manual✓
