Description:
APC by Schneider Electric Rack PDU, Switched, 1U, 16A, 208/230V, (8)C13 - Switched - IEC 60320 C20 - 200 V, 208 V, 230 V - 8.20 ft Cord Length - 1U - Rack-mountable
The APC by Schneider Electric Switched Rack Power Distribution Unit (PDU) distributes power to devices in the rack. It can be monitored through Web, Telnet, SNMP, SSH, StruxureWare Data Center Expert® interfaces.
Outlets: The outlets connect the Rack PDU to equipment in your rack or enclosure. Each outletallows independent control of the connected equipment and the Rack PDU firmware also provides Outlet User accounts. The PDU has eight IEC-320-C13 outlets.
Power cord: The Rack PDU has an IEC-320-C20 inlet on the front of the unit to connect to the power cord. The power cord connects the Rack PDU to one power source. The cord connects to the front of the Rack PDU for easier mounting and user access. The 8 foot (2.4 meter) cord terminates with a C20 plug.
Digital display: The digital display shows the aggregate current being used by th
Features
- PDU improves efficiency, uptime and growth of data centers
- With switched PDU, remotely monitor, connect or disconnect data center loads
- IEC 60320 C20 plug/connector type for better, dependable connectivity and desired power output
- 200 V input voltage for maximum feasibility and added productivity
- 208 V AC output voltage for maximum dependability and added productivity
Specifications:
| Warranty |
| Additional Warranty Information |
2 years repair or replace |
| Technical Information |
| Plug/Connector Type |
IEC 60320 C20 |
| PDU Type |
Switched |
| |
Switched |
| General Information |
| Product Type |
PDU |
| Manufacturer Part Number |
AP7921B |
| Manufacturer Website Address |
http://www.schneider-electric.com |
| Manufacturer |
Schneider Electric SA |
| Product Name |
Rack PDU, Switched, 1U, 16A, 208/230V, (8)C13 |
| Brand Name |
APC by Schneider Electric |
| Physical Characteristics |
| Weight (Approximate) |
5.5 lb |
| Mount Type |
Rack-mountable |
| Rack Height |
1U |
| Cord Length |
8.20 ft |
| Height |
1.7" |
| Width |
17.5" |
| Depth |
4.3" |
| Power Description |
| Input Voltage |
230 V |
| |
208 V |
| |
200 V |
| |
200 V |
| |
230 V |
| |
208 V |
| Output Voltage |
208 V AC |
| |
208 V AC |
| Input Current |
20 A |
|
| Miscellaneous |
| Package Contents |
- Rack PDU, Switched, 1U, 16A, 208/230V, (8)C13
- Installation guide
- Rack mounting brackets
- User manual
|
| Certifications & Standards |
cUL Listed|CE|CSA|GOST|IRAM|MIC|UL Listed|VDE|VCCI |
| Environmentally Friendly |
Yes |
| Environmental Certification |
RoHS |
| Mercury Free |
Yes |
| Green Premium |
Yes |
| Optimized Energy Efficiency |
Yes |
| Product Take Back Program |
Yes |
| RoHS Exemption Information |
https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP7921B_ROHS_DECLARATION&p_FileName=AP7921BKIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL |
https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=458562852&lang=en-us |
| EU RoHS Declaration URL |
https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=458562852&lang=en-us |
| Environmental Profile Availability |
https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612033_EN |
| End of Life Manual Availability |
https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612033_EN |
| REACH free of SVHC |
No |
| California Proposition 65 Warning |
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov |
|
