SIIG 4K 60Hz 18Gbps HDMI over IP Matrix - Encoder (TX) 394ft TAA Compliant - Transmits 4K@60Hz HDMI signal up to 394ft (120m) over a single Cat6/7 cable - DIP Switch - AV Over IP - PoE - One-to-One / One-to-Many / N to M Multi-casting - Up to 1023 transmitter units - 5x5 VideoWall - KVM - USB - HDCP 2.2 - HDR 10 - 3.5mm Stereo - S/PDIF - Bi-directional IR - RS-232 Control - ESD Protection - TAA Compliant - 3 years warranty - Kit (CE-H28A11-S1) - Decoder (RX) (CE-H27G11-S1) - Controller (CE-
Overview
HDMI over IP Matrix - Encoder (TX), transmits 4K@60Hz HDMI signal up to 394Ft (120m) over a single Cat6/7 cable, PoE, One to One, One to Many, Multi-casting, Video Wall, KVM, 18Gbps, HDCP 2.2, HDR 10, 7.1ch, Bi-directional IR, RS-232 Control, TAA Compliant, Kit (CE-H28A11-S1), Decoder (RX) (CE-H27G11-S1)
Features
Flexible matrix function to extend HDMI HDMI audio/video signals to the remote displays/monitors over UTP Cat6/7 cable up to 394ft (120m) and send the 4K@60Hz Ultra HD HDR resolution to the receiver for stable transmission and cost saving. Allows multiple receivers to be used simultaneously in multiple configurations
Specifications:
| Warranty |
| Limited Warranty |
3 Year |
| Media & Performance |
| Twisted Pair Cable Standard |
Category 7 |
| Media Type Supported |
Twisted Pair |
| Power Description |
| Frequency |
60 Hz |
| |
50 Hz |
| Video |
| Graphics Modes |
4K |
| Maximum Video Resolution |
4096 x 2160 |
| Technical Information |
| Connectivity Technology |
Wired |
| Maximum Operating Distance |
393.70 ft |
| Number of Input Devices Supported |
1 |
| General Information |
| Product Type |
Video Extender Transmitter |
| Manufacturer Part Number |
CE-H27F11-S1 |
| Manufacturer Website Address |
http://www.siig.com |
| Manufacturer |
SIIG, Inc |
| Product Name |
4K 60Hz HDMI over IP Matrix- Transmitter |
| Brand Name |
SIIG |
| Interfaces/Ports |
| USB |
Yes |
| Number of Network (RJ-45) Ports |
1 |
| Network (RJ-45) |
Yes |
| Number of USB Ports |
2 |
| Number of HDMI Inputs |
1 |
| HDMI In |
Yes |
| Physical Characteristics |
| Form Factor |
Wall Mountable |
| Transmitter Height |
1.09" |
| Transmitter Width |
5.19" |
| Transmitter Depth |
6.81" |
| Transmitter Weight (Approximate) |
1.41 lb |
| Product Color |
Black |
|
| Miscellaneous |
| Application/Usage |
Shopping Center |
| |
Lecture Hall |
| |
Retail Store |
| |
Airport |
| |
Control Center |
| |
Digital Signage System |
| |
Exhibition |
| |
Restaurant |
| |
Retail Store |
| |
Shopping Center |
| |
Airport |
| |
Control Center |
| |
Digital Signage System |
| |
Exhibition |
| |
Lecture Hall |
| |
Restaurant |
| Package Contents |
- 4K 60Hz HDMI Over IP Matrix- Transmitter
- 1x 3.5mm IR Emitter Extension Cable
- 1x DC Power Adapter, 5V/2A
- 1x Mounting Kit
- 1x User Reference Guide
|
| Country of Origin |
Taiwan |
|
