Server Technology C2WG08HC-2CB PRO2 Outlet Power Sensing 1U
Server Technology
SALE PRICE$1,018.00
REGULAR PRICE $1,198.00
Product Overview:
Switched POPS PRO2, Per Outlet Power Sensing, 1U, 8 x IEC C13 Outlets, Input Amp Meter, 208V 30A w/ NEMA L6-30P Connector
MFG#:C2WG08HC-2CBA2DAC
Product Category:PDU
Platform:PRO2
Additional information
Description:
| The Server Technology® PRO2 Switched POPS PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® and POPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input and at each output. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Switched POPS "Master" PDU can be connected to as many as three (with optional module) PRO2 Switched POPS "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration. | |
| Manufacturer | Server Technology, Inc |
| Manufacturer Part Number | C2WG08HC-2CBA2DAC |
| Manufacturer Website Address | http://www.servertech.com |
| Brand Name | Server Technology |
| Product Series | PRO1 |
| Product Model | C2WG08HC-2CBA2DAC |
| Product Name | Switched POPS PDU - 5.0kW, C2WG08HC-2CBA2DAC |
| Product Type | PDU |
| Technical Information: | |
| PDU Type | Switched |
| Phase | Three Phase |
| Plug/Connector Type | NEMA L6-30P |
| Receptacle Type | IEC 60320 C13 |
| Receptacle Detail | 8 x IEC 60320 C13 |
| Protection Type | Fuse Double Pole |
| Power Description: | |
| Input Voltage | 230 V AC |
| Output Voltage | 230 V AC |
| Power Rating (Watt) | 5000 W |
| Input Current | 30 A |
| Management: | |
| Management |
|
| Interfaces/Ports: | |
| Network (RJ-45) | Yes |
| Physical Characteristics: | |
| Mount Type | Rack-mountable |
| Rack Height | 1U |
| Height | 1.8" |
| Width | 17.2" |
| Depth | 7" |
| Miscellaneous: | |
| Country of Origin | United States |
| Warranty: | |
| Warranty | 2 Year |
