Raritan PX3-5118R 3PH 208V AC 30A 6 outlets 1U PDU

Name: Raritan PX3-5118R 3PH 208V AC 30A 6 outlets 1U PDU
Brand: Raritan
SKU: PX3-5118R
Price: 1106.18 USD
Availability: InStock

Raritan

MSRP: $1,349.00

Regular Price $1,146.65

Discount Price: $1,106.18

(You save $242.82 )

UPC:

Shipping:: Free Shipping

Product Overview:: 3PH, 208V AC, 30A (24A/PH rated); 6 outlets: 6x C19; plug: NEMA L15-30P (Delta Rear feed), 8.6kVA; Outlet Metered/Switched, 1U horizontal PDU

MFG#:: PX3-5118R

Product Category:: PDU

Platform:: PX3

Metering and Switching:: Outlet Metered and Switched

Total Outlets:: 6

Plug Type:: NEMA L15-30P

Input Phase:: 3 Phase Delta (L-L)

Power Capacity:: 8.6 kW

Input Voltage:: 208 V

Input Current:: 30

Form Factor:: 1U

Remote Switching:: 1

Manufactures Website:: https://www.raritan.com

Manufactures Product Page:: https://www.raritan.com/product-selector/pdu-detail/PX3-5118R

Model or Line:: PX3

Detail

Description:

Monitored and switched rack power distribution unit (1U [horizontal], 8.6kVA, 6 outlets). INPUT: 208v (3-phase DELTA), 30a - NEMA L15-30P plug (3P4W); OUTPUT: 6@ C19 outlets; on 3@ 2-pole, 20a Overcurrent Protectors; FEATURES: Billing-Grade (+/- 1%) Energy Metering [kW, kVA, V, A, Power Factor] - per inlet, per breaker/fuse, per outlet; Remote network monitoring via HTML, JSON-RPC, SSH, Telnet, MODBUS/TCP, and SNMPv3. Onboard embedded processor with minimum 536MHz clock speed, 16MB SPI Flash, and 64MB DDR2 RAM. Cascading upto 16 PDU's using single Ethernet or USB connection. Environmental monitoring [temp/humidity] capable – up to 32 sensors. Individual outlet numbers labeled on chassis. Automated deployment via TFTP, DHCP, SSH(CLI), or USB Flash Drives. WiFi Capable. USB Webcam Capable. iPad/iPhone/Android App. Dual 10/100/1000 Ethernet port. Tri-color status LED per receptacle. Breaker metering and alarming (0V detection). Max Dimensions 440mm x 183mm x 44mm (17.3in x 7.2in x 1.7in). Max Weight TBD. Maximum ambient temperature 60C at full load.

Features

Securelock

Energy Metering

Voltage (V), Current (A), Active Power (kW), Real Power (kVA), Energy (kWh), Power Factor

Metering Accuracy

ISO/IEC 62053-21 1%

Remote Outlet Switching

Yes

Metering per input line

Yes for all models

Metering per Branch Circuit Breaker

Yes

Environmental Sensor Ready

Yes

Compatible Sensors

Temperature, Humidity, Air Flow, Differential Pressure, Water Leak, and Contact Closure.

Cascading

Yes, Max 16 PDUs can be daisy chained using a USB or Ethernet connection.

Networking

(10/100/1000 Base T) Ethernet, Secondary redundant (10/100 Base T) Ethernet. Optional WiFi (802.11 a/b/g/n).

Onboard Display

Color, matrix LCD display : Voltage, current, or active power (per line, per breaker, or per receptacle / outlet); Alarms; Configuration information (name, ratings, IP / Networking information).
