Description:
3PH, 208-240V AC, 50A (40A/PH rated), 2 lines, input type: 2x Hubbell CS8365C (Delta), output type: 2x Hubbell CS8364, 2U, high resolution color display, Ethernet, serial, 2x USB-A, USB-B and sensor connections
Features
Energy Metering
Voltage (V), Current (A), Active Power (kW), Real Power (kVA), Energy (kWh), Power Factor
Metering Accuracy
ISO/IEC 62053-21 1%
Remote Outlet Switching
No
Metering per input line
Yes for all models
Metering per Branch Circuit Breaker
No
Environmental Sensor Ready
Yes
Compatible Sensors
Temperature, Humidity, Air Flow, Differential Pressure, Water Leak, and Contact Closure.
Cascading
Yes, Max 16 PDUs can be daisy chained using a USB or Ethernet connection.
Networking
(10/100/1000 Base T) Ethernet, Secondary redundant (10/100 Base T) Ethernet. Optional WiFi (802.11 a/b/g/n).
Onboard Display
Color, matrix LCD display : Voltage, current, or active power (per line); Alarms; Configuration information (name, ratings, IP / Networking information).
Specifications
Input
Input Plug
(2) CS8365C (3P4W)
Nominal Voltage
208V
Maximum Input Current
50A
Rated Input Current
40A
Power Capacity
0kVA
Cord Length
(2) 3m
Output
Nominal Voltage
208V
Receptacles (Output Connections)
(2) Hubbell CS8364
Overload Protection
NA
Physical
Dimensions (WxDxH)
17.3in x 15.8in x 3.5in; 440mm x 400mm x 88mm
Unit Weight
18.8 kg
Shipping Weight
23 kg
Shipping Dimensions
715mm x 545mm x 530mm
Mounting
RACK-KIT-PX-2U-T1
Environmental
Operating Temperature/Environment
60 C
Operating Relative Humidity
85%
Operating Elevation
0-6000ft
Conformance
Regulatory Approvals
UL
Warranty
Standard 2 years manufacturer warranty
