3" Core PermaSleeve Heatex Polyolefin 24 to 20 Gauge Wire Marking Sleeves
Brady
SALE PRICE$1,207.77
REGULAR PRICE $1,649.00


UPC:662820820437
MFG#:2HX-094-2-BK
Product Category:Printer Labels
Additional information
Overview
Heat-Shrink PermaSleeve® HX Polyolefin (B-7642) Wire Marking Sleeves are 2:1 heat shrinkable, high-temperature rated, highly flame retardant and very flexible.
- Supplied roll form in a flattened format on a carrier designed for use with computer driven printers
- Meets SAE-AMS-DTL-23053/5 Class 1 & 3, SAE-AS-81531, MIL-STD-2002
- Tested per ASTM E162 and ASTM E662
- Operating temperature of -40°F to 248°F (-40°C to 120°C)
- A ribbon is required to print this material. Use Part Number R6707-WT
Specifications
Key Characteristics | ||
Prod Number | 117315 | |
Product Number | 117315 | |
UPC | 662820820437 | |
UOM | Roll of 2500 Each | |
Quantity per Roll | 2500 | |
Trade Name | PermaSleeve® | |
Brand Name | Brady® |
Dimensions | Dimensions | 0.182 in H x 2 in W |
Height | 0.182 in | |
Width | 2 in | |
Sleeve Size | 0.094 in Dia x 2 in W | |
Vertical Repeat | 0.5 in | |
Recovered Diameter | 0.047 in | |
Recovered Wall Thickness | 0.02 in | |
Web Width | 3.49 in | |
Diameter as Supplied | 0.094 in | |
Core Diameter | 3 in |
